Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Hysik
-
Model Number:
-
08A-2013-104-xx
-
Number of Contacts:
-
3/4Pin
-
IP rated:
-
IP67
-
Rated Volgate:
-
60V
-
Rated Current:
-
4A
-
Wire Size:
-
26AWG
-
Coding:
-
A-coded/D-coded
-
Mating Type:
-
Full Thread
-
Sensor Connector Mounting:
-
Straight/Right angled
-
Screw Thread Size:
-
M8X1.0mm
-
Body:
-
Metal
Quick Details
-
Type:
-
Circular connector
-
Application:
-
Sensors/actuators/Encoders/Automation and Manufacturing industries
-
Gender:
-
Female/male
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Hysik
-
Model Number:
-
08A-2013-104-xx
-
Number of Contacts:
-
3/4Pin
-
IP rated:
-
IP67
-
Rated Volgate:
-
60V
-
Rated Current:
-
4A
-
Wire Size:
-
26AWG
-
Coding:
-
A-coded/D-coded
-
Mating Type:
-
Full Thread
-
Sensor Connector Mounting:
-
Straight/Right angled
-
Screw Thread Size:
-
M8X1.0mm
-
Body:
-
Metal
Hysik Electronics M8 Connectors & Cable Assemblies are small, industrial M8 connectors developed to meet the demand for increased signal carrying capabilities in space-saving designs. M8 Connectors & Cable Assemblies offer 1.5A-4A rated current, 30A-60V voltage, and ≥ 100 MΩ insulation resistance. M8 Connectors & Cable Assemblies provide IP65/IP67 protection and meets IEC 61076-2-104 standards with a surge voltage category II and Pollution degree of 3. The M8 series is available in male and female panel mount connectors and cable assemblies.
1. Safe use in the field, thanks to a high degree of protection,high tensile strength, abrasion and notch resistance
2. Flexible: connectors for on-site assembly,extremely high winding and unwinding strength
3.Soldering connection: proven connection technology for a large selection of different conductors
4.M8 extension cable or Flying leads(open cable ends),with good oil resistance/ chemical resistance
5.2 3 4 5 6 8 poles are available .(
High temperature 260 degree
,solder reflowing )
6.90 degree angled or straight(180 degree) overmolded M8 connector with PUR or PVC cable
7:Cable jacket with different colors,grey,black,orange,yellow,blue,overmolded color can be customized.
8:Connector Screw/Nut:Plastic/Brass/Stainless steel
9:A-coding/B-coing/D-coding
Packing:One piece packing in a small seal bag,then put in a small box
Shipping:Via international express,such as DHL UPS TNT or by sea/by air
Our Product Ranges
Standard products (M5, M8, M12, 7/8",M16, M23), waterproof IP68 connectors, valve connectors, AISG cables ,wire harness and connectors that comply to IEC and IEEE. Our products are mainly used in the fields of industry, automation, IoT, telecommunication, automotive, energy and smart machines,a durable and reliable connectivity solution is required to maximize output.
We are able to offer tailor-make solutions that suit the need of our customers from initial ideals to finished products to meet either standard or harsh environment signal and power transmission application. Our wide range of metric circular connectors and cable assembly fit almost any standard sensor or actuator application and includes features such as accurate IP ratings, a wide range of cable jackets, and multiple contacts pin configurations, and high quality rugged materials.
