Quick Details
-
Bottle Volume(ml):
-
1500 ml
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
disen
-
Year:
-
new
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
2850*1550*1850mm
-
Hollow part volume:
-
1500ml
-
Clamping Force (kN):
-
100
-
Power (kW):
-
21
-
Weight (KG):
-
1500 KG
-
Name:
-
water blow molding machine
-
Key words:
-
tank blow molding machine
-
Type:
-
water tank blow molding machine
-
raw material:
-
PET/PP/PE/PC
-
Theoretical yield:
-
1350-1800 pcs/h
-
Allow bottle diameter:
-
D30-D45
-
Allow bottle height:
-
320mm
-
Cavity:
-
2-cavity
-
Molding stroke:
-
145mm
-
Actual power consumption:
-
8kw
Quick Details
-
Neck Diameter(mm):
-
28 mm
-
Max.Bottle Diameter(mm):
-
105 mm
-
Max.Bottle Height(mm):
-
320 mm
-
Bottle Volume(ml):
-
1500 ml
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
disen
-
Year:
-
new
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
2850*1550*1850mm
-
Hollow part volume:
-
1500ml
-
Clamping Force (kN):
-
100
-
Power (kW):
-
21
-
Weight (KG):
-
1500 KG
-
Name:
-
water blow molding machine
-
Key words:
-
tank blow molding machine
-
Type:
-
water tank blow molding machine
-
raw material:
-
PET/PP/PE/PC
-
Theoretical yield:
-
1350-1800 pcs/h
-
Allow bottle diameter:
-
D30-D45
-
Allow bottle height:
-
320mm
-
Cavity:
-
2-cavity
-
Molding stroke:
-
145mm
-
Actual power consumption:
-
8kw
|
Machine parameters |
Unit |
Model |
|||
|
CJS-2L-2 |
CJS-06L-2 |
CJS-6L-1 |
CJS-06L-4 |
||
|
Theoretical yield |
pcs/hr |
1350-1800 |
1500-2200 |
450-700 |
2300-3600 |
|
Allow bottle diameter |
mm |
D30-D45 |
D30-D45 |
D30-D120 |
D30-D38 |
|
Allow bottle diameter |
mm |
D105 |
D65 |
D175 |
D65 |
|
Allow bottle height |
mm |
320 |
245 |
260 |
235 |
|
Cavity |
Cavity |
2 |
2 |
1 |
4 |
|
Molding stroke |
mm |
145 |
90 |
195 |
90 |
|
Machine capacity |
kw |
21 |
21 |
21 |
38 |
|
Actual power consumption |
kw |
8 |
6 |
13 |
16 |
|
Working gas pressure |
Mpa |
≤0.8 |
≤0.8 |
≤0.8 |
≤0.8 |
|
Blowing gas pressure |
Mpa |
≤3.0 |
≤3.0 |
≤3.0 |
≤3.0 |
|
Machine size |
M |
2850x1550x1850 |
2850x1550x1850 |
2850x1550x1850 |
3250x1650x1850 |
|
Host weight |
T |
1.5 |
1.1 |
1.8 |
2.1 |
multifunctional plastic bottle blowing machine is divided into two major control systems (customer can choose freely), one is controlled by time relay, and the other is PLC touch screen computer control, which can control technical parameters more accurately. This machine is easy to operate and safe. It adopts double emergency stop control in different positions, as well as single-point moving revelation button and double-point start button control in different positions, which makes the operator convenient in operation. This machine only needs one person to operate, no special training is required, and the machine has internal Special high and low pressure air storage device, users can supply gas by single gas source or dual gas source. The clamping device adopts double crank clamping and large clamping force. The machine is very simple to install and the operator operates and maintains. water tank blow molding machine,tank blow molding machine,automatic water tank blow molding machine for sale,determent bottle blow molding machine,water blow molding machine.
Multifunctional plastic bottle blowing machine is suitable for blowing carbonated beverage bottles, mineral water bottles, cosmetic bottles, oil bottles, space cups, jars, medicine bottles, etc. Plastic hollow containers (PET.PC.AS.PE...)
Infrared multi-function plastic preform heater is a three-phase four-wire 380V power supply (also available with 220V power supply). The machine is divided into seven layers of heating lamps, which are divided into four heating zones. The electrical box contains electric heating control components. The heat time is generally about 5-8 minutes. The temperature is sent to the temperature controller by the thermocouple for automatic temperature control, so that the temperature inside the heating box is smoothly controlled, the infrared penetrating power is strong, the heating is uniform, fast and reliable, and the preform is ideal. The heating effect is carried out after one cycle of the preform is heated, and the specific temperature is adjusted according to the shape of the bottle.water tank blow molding machine,tank blow molding machine,automatic water tank blow molding machine for sale,determent bottle blow molding machine,water blow molding machine.
The unit has excellent equipment, stable product quality, wide application range, low investment, low cost, low power consumption, quick investment and convenient operation. It is a mineral water, beverage, pesticide, chemical reagent, medicine, grease and other production plants. The ideal packaging machinery for widespread use.
