Quick Details
-
Applicable Models:
-
multi-cars
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ITCARDIAG
-
Model Number:
-
X431 Pro3s + V5.0
-
Warranty:
-
12 Months
-
Product Name:
-
LAUNCH X431 PRO3S+ V5.0
-
Certification:
-
CE
-
Function 1:
-
Active tester ( Bi-directional Control )
-
Function 2:
-
ecu coding
-
Function 3:
-
Guiding Function
-
Function 4:
-
ADAS Calibration
-
Function 5:
-
TPMS Diagnostic Function
-
Function 6:
-
key programming Function
-
Function 7:
-
AF Adjustment
-
Function 8:
-
For 2017+ FCA Vehicles
Quick Details
-
Car Fitment:
-
Universal
-
Voltage:
-
12v
-
Power:
-
w
-
Applicable Models:
-
multi-cars
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ITCARDIAG
-
Model Number:
-
X431 Pro3s + V5.0
-
Warranty:
-
12 Months
-
Product Name:
-
LAUNCH X431 PRO3S+ V5.0
-
Certification:
-
CE
-
Function 1:
-
Active tester ( Bi-directional Control )
-
Function 2:
-
ecu coding
-
Function 3:
-
Guiding Function
-
Function 4:
-
ADAS Calibration
-
Function 5:
-
TPMS Diagnostic Function
-
Function 6:
-
key programming Function
-
Function 7:
-
AF Adjustment
-
Function 8:
-
For 2017+ FCA Vehicles
LAUNCH X431 PRO3S+ has the upgrade version now , it is V5.0, supports CANFD/DOIP protocl now !
Type 1 is LAUNCH X431 PRO3S+ Global version , it works in Global , NO IP limited !
LAUNCH X431 PRO3S+ supports 24 kinds of Language :
Italian, English, Chinese Simplified, Chinese Traditional, German, Japanese, Russian, French, Spanish, Portuguese, Polish,
Turkish, Dutch, Greek, Hungarian, Arabic, Danish, Korean, Persian , Romanian, Serbian, Finnish, Swedish, Czech
Warm TIP : The factory presets the language and the model software in English. After switching the language, customer needs to re-download the model software in the corresponding language.
it is the only product in this price range that is compatible with CAN-FD protocol and supports the latest For GM vehicles
manufactured after 2020. Adopts advanced CRC algorithms to accommodate more data from 8 to 64 bytes in the CAN frame, which runs
faster than other products and reduces the risk of undetected errors to greatly enhance the user experience.
Supports For Chevrolet Onix 2020-2021 year
Supports For Chevrolet Tracker 2020 year
Supports For Chevrolet Suburban 2021 year
Supports For Chevrolet Tahoe 2021 year
Supports For Buick
Supports For Cadillac Escalade 2021 year
Supports For Cadillac Escalade 2021 year
Supports For GMC Yukon 2021 year
Supports For GMC Yukon XL 2021 year
Supports For Holden
Supports For DAEWOO
Supports For Alpheon
Supports For Ravon
Supports For Pontiac
Supports For Saturn
Supports For Hummer
DOIP
With Diagnostics over DoIP, diagnostics introduced over UDS are used over TCP/IP and Ethernet. This enables much higher data rates
than with CAN. That makes LAUNCH CRP909X save both in terms of time and expenses in the case of complex diagnostic tasks and flash
applications. Compatible with BMW (F&G chassis), Volvo models (2018 later), Land Rover & Jaguar models (2017 later).
( Note : this is car list that CANFD and DIOP supports , CRP919E also supports other cars , more than about 100+ brands , like for
bmw , for vw , for ford etc , there has the detailed car list in the following description , you can check )
FCA/SGW AutoAuth :
FCA SGW Access: For the 2018+ FCA vehicles (For Fiat, For Chrysler, For Jeep, For Alfa Romeo, etc.) equipped with the Security
Gateway module, the LAUNCH X431 PRO3 ACE car scanner can help you to log in to the FCA account and perform diagnostic functions such as clearing DTCs, bi-directional tests, and calibrations.
For Renault SGW Access: Serve 2019+ For Renault SGW vehicles include for CLIO V, for CAPTUR II, for CAPTUR II CN, for MEGANE IV
ph2, for ESPACE V ph2, for TALISMAN/SM6 ph2, for NEW ZOE, for ARKANA CN, for XM3/NEW ARKANA, for NEW SANDERO/LOGAN, etc. Unloking security gateway to perform service function, active test, coding, programming, etc.
Note : This Function need have the account in FCA Website first .
to precision with our advanced technology that allows you to easily identify and locate faults in your vehicle's electrical
system. With topology mapping, you can quickly and accurately diagnose issues, saving you time and money on costly repairs.
* Our cutting-edge diagnostic tools provide a comprehensive view of your vehicle's electrical system, giving you a detailed map of all the components and their connections. This allows you to quickly pinpoint any faults and troubleshoot with ease. Whether
you're a professional mechanic or a DIY enthusiast, our topology mapping feature is a game-changer that will take your diagnostic capabilities to the next level.
* Don't settle for outdated diagnostic tools that leave you guessing. Upgrade to our topology mapping technology and experience the future of automotive diagnostics today. With our products, you'll have the power to diagnose and fix problems with confidence, ensuring your vehicle runs smoothly and efficiently. Try it now and see the difference for yourself!
The Full Systems of the car mainly including Drive System, Chassis System, Body System, Electrical system :
1.PCM(Drive System): Engine, Transmission, Transfer case, Electrical Machine Electronics, Fuel Pump, Gear, and more...
2. Chassis System: Accumulator Management Electronics, Steering, Integrated Chassis Management, Tyre Pressure Control, Active
Cruise Control, Braking System, Suspension, TPMS and more...
3.BCM(Body System): SRS Airbag, Camera, Audio Radio, Gateway, Cluster Dashboard, Rain Sensors, Charging Interface Module, Parking
Assistance, Power Control Unit, Touch box, Light, Battery Charging System, Head up Display, Wipe Control System, Roof, Seat & Door
Motor system, Immobilizer, ABS ESP system, Air Condition.Electric Windows, Telephone, and more...
4.Electrical System: Including Centralized control system for engine and power transmission, Chassis integrated control and safety
system, Intelligent body electronic system, Communication and information / entertainment system.
It supports the detailed Function :
--read fault codes: read and decode the DTCs to identify where the fault location is;
--clear fault codes: erase the DTCs to turn off the MIL after repairs;
--retrieve ecu information: allows you to retrieve vehicle information;
--Graph live data stream: view the dynamic data stream to determine vehicle condition
--ECU Coding : Match, learn, or code the new ECU; Customize your car, unfold the hidden features, or disable the annoying
functions; Reprograms the adaptive data for certain components after repairs.
--Active Test ( Bi-directionnal Control ) : Actuate solenoids and actuators for active testing, send commands to
systems/components to test their working status, without using the vehicle controls.
With the Diagnose Function , you can enhance performance, save energy, reduce emissions and more as following:
For Engine: detect common issues as Poor lubrication, Failing oil pump, Oil deposits and debris, Inadequate fuel and air
compression, Leaking engine coolant, Blocked engine radiators, Prolonged engine detonation, Damaged oxygen sensors, Aged spark plugs, etc.
For SRS: pinpoint the trouble area as: a bad seat belt, a corroded crash sensor, or some water intrusion in a connector, etc.
For ABS: diagnose Blown sensor fuse, Low brake fluids, and Faulty sensor, etc.
For Transmission: avoid Grinding or shaking sensation in gear, Whining, humming or clunking noises, Burning smells, Gears Slipping, Low or Leaking Transmission Fluid, etc.
For TPMS: verify problems of Low tire pressure, Faulty in tire pressure monitor control module, Unknown tire sensor, Failure to identify tire sensor, etc.
What is Full Bi-Directional Control ( ACTVE TEST) function?
* With this diagnostic tool's Active Test, you can output the command into the ECU in order to turn on/off actuators, to find faults in the subsystems of your car effortlessly, without using the vehicle's control;
* [ Turn on the radiator fan | Modulate the throttle | Open/close windows | Operate mirrors | Turn on/off the lights | Turn on/off the sound horn | Test door lock … ]
* Available test varies by the vehicle manufacturer, year, and model.
What is ECU CODING Function ?
Why does the car not work normally after replacing ECUs/ modules?
When an ECU/module is damaged, you have to replace a new one. After replacing the ECU/module, you have to follow the strict procedures of the manufacturer to match, learn, code, or even program it before it functions normally. Otherwise, the car cannot start or some parts cannot work normally.
What can LAUNCH X431 PRO3S+ Scanner do?
Featuring ECU/Module replacement functions, LAUNCH X431 PRO3S+ Bi-directional Scanner can help you initialize, match, relearn, or code the newly replaced ECU/module to get it back on track.
ECU Coding: Customize Your Car in Minutes
* Same as other LAUNCH X431 High-end OE-level scan tool , LAUNCH X431 PRO3S+ has the capability of ECU coding to change preprogrammed options in the software, helping you customize your car faster as needed.
* Optimally code your car by changing some settings to fit your needs, such as setting alarms, doors locking, etc.
* Access the ECU to make full use of the hidden features or disable the car’s annoying functions, like activating the auto side mirrors folding function, disabling the automatic engine Start-Stop function, etc.
* Provide excellent solutions for issues of drivability, power loss, fuel efficiency, etc. to improve the car’s performance.
* Reprogram the adaptive data for certain components after repairs or replacements.
* ECU Online Coding is available for BMW, VW, Porsche, Renault, etc.
Please Note: ECU Coding changes preprogrammed options which depend on the type and number of electronic features already built in. Thus, ECU coding is not universally compatible and varies for different vehicles.
LAUNCH X431 PRO3S+ V5.0 Supports TPMS Diagnostic function ( need works with X431 tsgun )
LAUNCH X431 PROS3+ can work with wireless tire pressure diagnostic tool (optional accessory) toachieve the features of TPMS activation, programming and learning.
a)Activation:to activate the sensor's IlD, wheel pressure, sensor frequency, tire temperature and battery status.
b)Programming:to program sensor data to a blank Thinkcar sensor, so as to replace a sensor that is in low battery and does not function properly. There are three sensor programming methods available:automatic, manual, and via activation replication.
c) Learning:to write the sensor ID into the vehicle ECU for sensor identification.
LAUNCH X431 PRO3S+ V5.0 Supports Key Programming Function ( need works with X431 X-prog 3 )
Features of LAUNCH X431 PRO3S+ car key programmer go beyond any other scan tools you’ll find at the same level. This LAUNCH X431 diagnostic tool can also be a capable IMMO service tool, providing fast, easy, and intuitive k-ey programming for VAG group vehicles with 2/3/3.5 gen. IMMO, and most Asian cars with low-level antitheft systems.
Add Key, Delete Key, Read Pin Code (All K-eys Lost), and more.
Need to pair with LAUNCH X431-PROG3 IMMO Programming box to have complete IMMO & K-ey Programming (read & wirte 1200+ EEPROM and MCU chips, etc.) for VW/Audi/Skoda/Seat models manufactured after 2008 with 4/5/5.5/6 gen. IMMO system.
NOT universally compatible. Reach us to check car coverage if necessary.
LAUNCH X431 PRO3S+ V5.0 Supports 12 in 1 graphic data stream
view and capture (record) real-time Live Data. This data including current operating status for parameters and /or sensor information can provide insight on overall vehicle performance. It can also be used to guide vehicle repair.
LAUNCH X431 PRO3S+ V5.0 Supports 36+ Special Reset Service Functions
LAUNCH X431 PRO3S+ V5.0 parameter:
Operating System : Android 10 OS
CPU : 2.0GHz 4 core
Screen Size : 10.1 inch 1280*800 FHD IPS Touch Screen
Battery : 6300mAH 7.6V
Memory : 4GB+64GB
Camera : Rear 8.0MP
WIFI : 2.4GHz&5GHz Dual-Frequency Wi-Fi, 4X faster transmission rate
Working Speed : 8X Faster AUTO VIN Technology, Time is Money!
Work Temperature : 0°C~50°C
LAUNCH X431 PRO3S+ V5.0 Packing List :
1pc X431 PRO3S+ V5.0 10.1 inch Tablet PC
1pc DBScar IV Bluetooth Connector
1pc OBD II Cable
1pc For Mitsubishi/Hyundai-12+16pin Cable
1pc For Benz-14pin Cable
1pc For Benz-38pin Connector
1pc For BMW-20pin Connector
1pc For Chrysler-6pin Connector
1pc For Ford-6+1pin Connector
1pc For GM/VAZ-12pin Connector
1pc For Honda-3pin Connector
1pc For Kia-20pin Connector
1pc For Nissan-14+16pin Connector
1pc For Toyota-17pin Connector
1pc For Toyota-22pin Connector
1pc Cigarette lighter Cable
1pc Double Clamp power Cable
1pc US Power Adapter 5V,2A
1pc EU * UK Power Adapter 5V,2A
1pc USB to micro data Cable
