Quick Details
-
Color:
-
17M~69G colors
-
Panel Size:
-
(Module)244x122mm, (Module)244x122mm
-
Place of Origin:
-
Guangdong, China, Guangdong, China
-
Model Number:
-
P7.62 Indoor Full Color LED Display
-
Pixel Pitch:
-
7.62mm, 7.62mm, 7.62mm
-
Pixel Composition:
-
1R1G1B
-
Working Voltage:
-
AC110V±10%, 50Hz-60 Hz
-
Viewable Angle:
-
Horizontal: 140°, Vertical: 120°
-
Refresh Frequency:
-
300 Hz~2440Hz
-
Transmission Distance:
-
≥72 hours
-
Temperature of Use Environment:
-
-20℃~+50℃
-
Certifications:
-
CE, ROHS,ISO14001,FCC,CCC
Quick Details
-
Application:
-
Exhibition hall, KTV, marketing,banquet hall
-
Type:
-
LED
-
Brand Name:
-
D-KING
-
Color:
-
17M~69G colors
-
Panel Size:
-
(Module)244x122mm, (Module)244x122mm
-
Place of Origin:
-
Guangdong, China, Guangdong, China
-
Model Number:
-
P7.62 Indoor Full Color LED Display
-
Pixel Pitch:
-
7.62mm, 7.62mm, 7.62mm
-
Pixel Composition:
-
1R1G1B
-
Working Voltage:
-
AC110V±10%, 50Hz-60 Hz
-
Viewable Angle:
-
Horizontal: 140°, Vertical: 120°
-
Refresh Frequency:
-
300 Hz~2440Hz
-
Transmission Distance:
-
≥72 hours
-
Temperature of Use Environment:
-
-20℃~+50℃
-
Certifications:
-
CE, ROHS,ISO14001,FCC,CCC
P7.62 Indoor led display Technical Parameters:
|
Model |
P7.62 Indoor Full Color LED Display |
|
Pixel Pitch |
7.62mm |
|
Pixel Composition |
1R1G1B |
|
Pixel Density |
17222/m² |
|
Scanning method |
1/8 |
|
Brightness |
1 2 00cd//m² |
|
Working Voltage |
AC110V±10%, 50Hz-60 Hz |
|
Average Power |
220W/m² |
|
Max. Power |
600W/m² |
|
Pixel No. on Unit Plate |
32×16 |
|
Module Size |
244mm×122mm |
|
Level up degree |
<1mm |
|
Viewable Distance |
7.62m-30m |
|
Viewable Angle |
Horizontal: 1 4 0°, Vertical: 1 2 0° |
|
Screen Weight |
35 kg/m² |
|
Driving Method |
Constant current |
|
Display Color |
17M~69G colors |
|
Display Color |
Manual/Automatic/Remote |
|
Grey Scale |
256~4096 |
|
Refresh Frequency |
300 Hz~2440Hz |
|
Refresh Frame Frequency |
60Hz |
|
Display Content |
TV picture, ads, video, live streaming video, picture and words |
|
Display Mode |
640×480, 800×600, 1024×768, 1280×960…1920×1200, 2048×640 |
|
Control Method |
Synchronous, asynchronous, remote and wireless |
|
Transmission Distance |
5E cable≤130M Multimode fibre≤500M monomode fibre≤10KM |
|
Transmission Distance |
≥72 hours |
|
Service Life of Led |
100,000 hours |
|
Mean Time Between Failure |
≥10,000 hours |
|
Dispersed Incontrollable Point |
<0.01% |
|
Continuous Incontrollable Point |
No |
|
Protecting Technology |
Waterproof (Front size IP65, back side IP54), dustproof, antisepsis, antistatic, and has such protection functions of over current, short circuit over voltage and low voltage. |
|
Temperature of Use Environment |
-20℃~+50℃ |
|
Moisture of Use Environment |
10%~90% |
|
Certifications |
CE, ROHS ,CCC,FCC,ISO14001 |
