Quick Details
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
China
-
Brand Name:
-
Derek
-
Dimension(L*W*H):
-
1670X1310X1050mm
-
Weight (KG):
-
350 KG
-
Product name:
-
DF6090
-
Model:
-
DRK1290/4060/6090/1390/1610
-
Type:
-
Water Cooling CO2 Laser Engraving Machines
-
Laser power:
-
60W/80W/100W/130W/150W
-
Working area:
-
400*300mm-1600* 2500mm
-
Control system:
-
Ruida 6442sS Control System
-
Power Supply:
-
220V/50HZ 110V/60HZ
-
Software:
-
Laser Works
-
Driving system:
-
Leadshine 3-phase Stepper Motor
-
Control Software:
-
Autocad, Coreldraw,Photoshop, etc.
Quick Details
-
Engraving Area:
-
1200*900mm/400*600mm/1300*900mm
-
Laser Type:
-
CO2
-
Engraving Speed:
-
0-60000mm/min
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
China
-
Brand Name:
-
Derek
-
Dimension(L*W*H):
-
1670X1310X1050mm
-
Weight (KG):
-
350 KG
-
Product name:
-
DF6090
-
Model:
-
DRK1290/4060/6090/1390/1610
-
Type:
-
Water Cooling CO2 Laser Engraving Machines
-
Laser power:
-
60W/80W/100W/130W/150W
-
Working area:
-
400*300mm-1600* 2500mm
-
Control system:
-
Ruida 6442sS Control System
-
Power Supply:
-
220V/50HZ 110V/60HZ
-
Software:
-
Laser Works
-
Driving system:
-
Leadshine 3-phase Stepper Motor
-
Control Software:
-
Autocad, Coreldraw,Photoshop, etc.
laser 6090/laser 9060 cutting engraving machine/lazer co2
Wifi control, one computer can control many machines .
3 years warranty.
CE Certificate for Europe Certificate for America.
Applicable materials:
wood, bamboo, jade, marble, organic glass, crystal, acrylic,plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials.
Applicable industries:
advertisement, arts and crafts, leather, toys, garments, model , building upholster, computerized embroidery and clipping, packaging and paper industry.
|
technical details
|
|
|
|
Model
|
DRk6090(4060/1290/1390/1490/1610)
|
|
|
Work area
|
600*900mm.etc
|
|
|
Laser power
|
80w (40/ 60/100/130 w option)
|
|
|
Laser type
|
co2
|
|
|
Water chiller
|
CW3000 (5000/5200 option)
|
|
|
Laser head No.
|
One
|
|
|
Linear rail
|
Taiwan Hiwin
|
|
|
Table
|
Blade & Honeycomb
|
|
|
Cooling mothod
|
Water cooling/water break protection
|
|
|
Engrave speed
|
0~1000mm/s
|
|
|
Cut speed
|
0~600mm/s
|
|
|
Resolution
|
±0.01mm
|
|
|
System
|
RDC6442s with Wifi
|
|
|
Software
|
Laserwork v8
|
|
|
Graphic format supported
|
BMP,PLT,DST,DXF,AI,JPG,etc.
|
|
|
Software supported
|
Autocad, Coreldraw,Photoshop, etc.
|
|
|
Laser output
|
0-100%
|
|
|
Operating temperature
|
0-45℃
|
|
|
Operating Humidity
|
5-95%
|
|
|
Working mode
|
Leadshine stepper motor ( Servo motor)
|
|
|
Gross power
|
1200w
|
|
|
Min shaping character
|
1*1mm English
|
|
|
Voltage
|
220V±10%, 50-60Hz, single phase ( 110V- option)
|
|
|
Resolution
|
4000DPI
|
|
|
Option 1
|
z axis motorized up-down
|
|
|
Option 2
|
Auto focus
|
|
|
Option 3
|
Remote controller
|
|
|
Package
|
Plywood case
|
|
|
Machine size
|
1400X1060X1105mm
|
|
|
Package size
|
1520X1120X1185mm
|
|
|
N.W
|
350KGS.etc
|
|
|
G.W
|
380KGS.etc
|
|
Welcome to Jinan Derek Laser Technology Co.,Ltd ~ ~
Derek Laser
is a high-tech modern enterprise integrating the R&D,production and sale. Our company has successfully developed laser engraving machine and laser cutting machine series products under advanced technology and professional management. We have obtained the trustand support of domestic and foreign user swith high quality products and complete service systems.
Welcome to join us , We are a big trustworthy family ~ ~
Looking forward to cooperating with you ~ ~
1.Water-proof plastic film package with foam protection in each corner
2.Solid Seaworthy Wood Box Package with Steel Belt
3.Save space as much as possible for container loading
