Professional 12v wind turbine 100w tulip wind power generator for wholesales

Professional 12v wind turbine 100w tulip wind power generator for wholesales

FOB Reference Price: Get Latest Price

≥2 Sets

US $382

≥50 Sets

US $227

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Model Number:: SV-100

Certification:: CE

Output Voltage:: 12/24V

Rated Power::: 100W

Maximum Power::: 120W

Rated Voltage::: 12/24V

Start-up Wind Turbine::: 2M/s

Rated Wind Speed::: 12M/S

Safety Wind Speed::: 35M/S

Wheel Diameter::: 1.2M

Number of Blades::: 5

Blades Material::: Aluminum Alloy

Generator type::: 3Phase Permanent Magnent Generator

Quick Details

Rated Power:: 100w

Place of Origin:: Jiangsu, China

Brand Name:: Great

Model Number:: SV-100

Certification:: CE

Output Voltage:: 12/24V

Rated Power::: 100W

Maximum Power::: 120W

Rated Voltage::: 12/24V

Start-up Wind Turbine::: 2M/s

Rated Wind Speed::: 12M/S

Safety Wind Speed::: 35M/S

Wheel Diameter::: 1.2M

Number of Blades::: 5

Blades Material::: Aluminum Alloy

Generator type::: 3Phase Permanent Magnent Generator

Introduction

Features
*Low start up steed, compact, light, beautiful and with little vibration;

*Easy installation, flange connection;

*Blades using aluminum alloy, spray-paint and oxidation treatment of the blades surface, strengthen the anti-corrosion level, more beautiful and durable. Color optional.
*Patented permanent magnet ac generator with special stator (maglev generator), effectively reduce torque, make only 1/3 torque of ordinary generator, well ensure the wind wheel, generator and the performance of whole system.
*Adopting MPPT intelligent micro controller effectively adjusts current and voltage.

H Style Wind Turbine

H Type Wind Turbine

Model	NE-100H	NE-200H	NE-300H	NE-400H	NE-500H
Rated Power	100W	200W	300W	400W	500W
Maximum Power	120W	220W	320W	420W	515W
Rated Voltage	12/24V
Start-up Wind speed	2M/S
Rated Wind Speed	12M/S
Safety Wind Speed	35M/S
Wheel Diameter	1M	1.2M	1.4M	1.4M	1.6M
Wheel height	1.2M	1.4M	1.6M	1.6M	1.8M
Number of Blades	5
Blades Material	Aluminum Alloy
Generator	Rare earth permanent magnetic levitation generator
Control System	Electromagnet
Speed Regulation	Automatically adjust wind ward direction
Work Temperature	-40~80℃
Design Life	20 years

H2 Type Wind Turbine

Model	NE-1000H	NE-1500H	NE-2000H	NE-3000H	NE-5000H	NE-10000H	NE-20000H
Rated Power	1KW	1.5KW	2KW	3KW	5KW	10KW	20KW
Maximum Power	1.2KW	2KW	2.2KW	3.5KW	5.5KW	12KW	23KW
Rated Voltage	48V	48/96V		96/120V	120/220V	360V	360V
Start-up Wind speed	2M/S					2.5M/S
Rated Wind Speed	12M/S
Safety Wind Speed	35M/S
Wheel Diameter	2.2M	2.55M	2.55M	2.85M	3.6M	5.8M	7.6M
Wheel height	2.4M	2.8M	3M	3.5M	4.5M	8M	10M
Number of Blades	5
Blades Material	Aluminum Alloy,Glass steel
Generator	Rare earth permanent magnetic levitation generator
Control System	Electromagnet
Speed Regulation	Automatically adjust wind ward direction
Work Temperature	-40~80℃
Design Life	20 years

Q Style Wind Turbine

Q Type Wind Turbine

Model	NE-100Q1	NE-200Q1	NE-100Q2	NE-200Q2	NE-100Q3	NE-200Q3	NE-300Q4	NE-400Q4
Rated Power	100W	200W	100W	200W	100W	200W	300W	400W
Maximum Power	130W	220W	130W	220W	130W	220W	310W	410W
Rated Voltage	12/24V
Start-up Wind Turbine	1.5M/S
Rated Wind Speed	10M/S	11.5M/S	10M/S	11.5M/S	10M/S	11.5M/S	11M/S	11M/S
Safety Wind Speed	45M/S
Top Net Weight	12KG	12.5KG	11.5KG	12KG	12KG	12.5KG	25KG	26KG
Wheel Diameter	1.1M	1.1M	1.1M	1.1M	1.1M	1.1M	1.4M	1.4M
Number of Blades	6	6	9	9	6	6	4	4
Blades Material	Aluminum alloy
Generator	Rare earth permanent magnetic levitation generator
Magnet	Electromagnet
Generator Case	Automatically adjust wind ward direction
Control System	Electromagnet
Speed Regulation	Automatically adjust wind ward direction
Work Temperature	-40~80℃
Design Life	20 years

R Style Wind Turbine

R Type Wind Turbine

Model	NE-100R	NE-200R
Rated Power	100W	200W
Maximum Power	130W	220W
Rated Voltage	12/24V	12/24V
Start-up Wind speed	2M/S
Rated Wind Speed	11M/S	11M/S
Safety Wind Speed	45M/S	45M/S
Top Net Weight	11KG	11.5KG
Wheel Diameter	0.9M	0.9M
Number of Blades	5
Blades Material	Nylon fibers
Generator	Rare earth permanent magnetic levitation generator
Control System	Electromagnet
Speed Regulation	Automatically adjust wind ward direction
Work Temperature	-40~80℃
Design Life	20 years
