Quick Details
-
Max. Resolution:
-
203dpi
-
Brand Name:
-
SNBC
-
Place of Origin:
-
Jiangsu, China
-
Accessory specification:
-
Others
-
Interface:
-
RS-232, USB(optional)
-
Dimensions:
-
334(L)*132(W)*148(H)mm (Without paper holder)
-
Paper roll OD:
-
Max.150mm
-
cut:
-
Full cut, partial cut
-
Paper roll ID:
-
12.5mm,25.4mm
-
Weight:
-
Approx.2kg (Without paper holder)
Quick Details
-
Max Paper Size:
-
82.5mm
-
Black Print Speed:
-
150mm/sec
-
Color Print Speed:
-
NULL
-
Max. Resolution:
-
203dpi
-
Brand Name:
-
SNBC
-
Place of Origin:
-
Jiangsu, China
-
Accessory specification:
-
Others
-
Interface:
-
RS-232, USB(optional)
-
Dimensions:
-
334(L)*132(W)*148(H)mm (Without paper holder)
-
Paper roll OD:
-
Max.150mm
-
cut:
-
Full cut, partial cut
-
Paper roll ID:
-
12.5mm,25.4mm
-
Weight:
-
Approx.2kg (Without paper holder)
1. Open structure and easy maintenance design
2. Up to 150mm/s high speed printing with low noise
3. Two paper paths, straight and curved
4. Large paper roll capacity, up to 150mm diameter
5. Easy semi-automatic paper loading
6. Two available paper out methods: full cut, partial cut
7. Support marked paper and continuous paper
8. Two sensors in paper path so as to detect mark and paper more
|
Item |
Parameters |
|
|
|
Print Method |
Direct Thermal |
|
Resolution |
203DPI |
|
|
Paper width |
80mm |
|
|
Print width |
Max.80mm |
|
|
Max.640 dot |
||
|
Print speed |
150 mm/s |
|
|
RAM memory |
SDRAM |
|
|
Flash memory |
4 MB |
|
|
Function |
Paper near end detection |
Photoelectric sensor |
|
Interface |
RS-232, USB(optional) |
|
|
Print head temperature detection |
Thermal resistor |
|
|
Print head position detection |
Micro switch |
|
|
Barcode |
Barcode |
JAN13 (EAN13),CODE 128, ITF |
|
UPC-A,UPC-E ,JAN8 (EAN8), CODE 39,CODE 93,CODABAR |
||
|
Fonts |
Fonts |
Standard ASCII, compressed ASCII Optional Asian character set(Simplified Chinese, traditional Chinese, Japanese, Korea) |
|
Fonts Process |
All fonts can be enlarged 1 to 6 times vertically and horizontally respectively, Rotation Print (0°, 90°, 180°, 270°),Bold, white/black reverse, underline, upside-down |
|
|
Graphics |
Graphics |
Support bitmap to be downloaded to RAM and FLASH: 256K |
|
Support direct bitmap print |
||
|
RAM bitmap:4k |
||
|
Media |
Paper type |
Continuous paper/marked paper |
|
Paper roll OD |
Max.150mm |
|
|
Paper roll ID |
12.5mm,25.4mm |
|
|
Paper thickness |
60~100 um |
|
|
Paper cut |
Full cut, Partial cut |
|
|
Reliability |
Print head lifetime |
100Km |
|
Cutter lifetime |
10,000,000 cuts |
|
|
MTBF |
360,000 hours |
|
|
Environment |
Operation environment |
0~50℃,20~90%RH(40℃) |
|
Storage environment |
-40~60℃,20~93% RH(40℃) |
|
Information kiosks
Multimedia and Internet kiosks
Document kiosks
Banking machines
Insurance self-service
Human resource kiosks
Boarding passes
Gaming/lottery
Information kiosk
Vending machine
ATM/EFT
