- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Veepai
-
Model Number:
-
CS69
-
Resolution:
-
3MP
-
Lens:
-
3.6mm HD Lens
-
APP:
-
OKAM PRO
-
Power Supply:
-
DC 12V
-
IR Distance:
-
30-40m
-
Audio:
-
Two-way Audio+alarm
-
Alarm:
-
Human Motion Detection Alarm
-
Waterproof:
-
IP65 Waterproof Level
-
Motion Detection:
-
PIR Motion Sensor
-
View angle:
-
120
Quick Details
-
Special Features:
-
Human Motion Tracking, NIGHT VISION, Motion Detection, Sound Detection, Waterproof / Weatherproof, PAN-TILT, Two-way Audio
-
Function:
-
Two-way Audio, PAN-TILT, Abnormal sound detection, RESET, Built-in Mic, NIGHT VISION, Waterproof / Weatherproof, Wide Angle
-
Customized support:
-
Online technical support, Customized logo, Software reengineering, OEM, ODM
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Veepai
-
Model Number:
-
CS69
-
Resolution:
-
3MP
-
Lens:
-
3.6mm HD Lens
-
APP:
-
OKAM PRO
-
Power Supply:
-
DC 12V
-
IR Distance:
-
30-40m
-
Audio:
-
Two-way Audio+alarm
-
Alarm:
-
Human Motion Detection Alarm
-
Waterproof:
-
IP65 Waterproof Level
-
Motion Detection:
-
PIR Motion Sensor
-
View angle:
-
120
Products Description
Product Paramenters
|
Model #
|
|
CS69
|
|
|
|||
|
APP Name
|
|
OKAM PRO
|
|
|
|||
|
Operating system
|
|
Embedded Linux
|
|
|
|||
|
Online visitors
|
|
Supports 4 visitors at the same time
|
|
|
|||
|
CPU/Image sensor
|
|
1/3’’ 4Mega CMOS Image Sensor
|
|
|
|||
|
Minimum illumination
|
|
0.5 Lux(Color mode), 0.1 Lux(B&W mode)
|
|
|
|||
|
Lens/Viewing angle
|
|
4mm@F2.0/101° Diagonal
|
|
|
|||
|
Night vision
|
|
IR LED light+LED light; Irradiation distance: 15~20 m
|
|
|
|||
|
Compression standard
|
|
H.264 main profile/Motion-JPEG/JPEG
|
|
|
|||
|
Data Rate
|
|
Main stream: 1440p(2560×1440）@25fps Substream：360p(640×360)@15fps
|
|
|
|||
|
Bit rate/maximum frame rate
|
|
128～4096kbps/30fps
|
|
|
|||
|
Image adjustment
|
|
Brightness and contrast are adjustable
|
|
|
|||
|
Audio Input
|
|
Built-in －38dB microphone
|
|
|
|||
|
Audio Output
|
|
Built-in 8Ω2 W speaker
|
|
|
|||
|
Sampling frequency/bit width
|
|
8KHz/16bit
|
|
|
|||
|
Compression standard/Bit Rate
|
|
G.711/64kbps
|
|
|
|||
|
Network interface
|
|
10Mbps/100Mbps adaptive /RJ45
|
|
|
|||
|
Network protocol
|
|
TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc.
|
|
|
|||
|
Wireless network
|
|
IEEE802.11b/g/n；Supports AP mode
|
|
|
|||
|
Wireless frequency
|
|
2.4~2.4835GHz
|
|
|
|||
|
Wireless security encryption
|
|
64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption
|
|
|
|||
|
Pan & Tilt
|
|
Pan 345° /Tilt 53°
|
|
|
|||
|
Preset position
|
|
Supports 16 (Mobile phone App supports 5) preset positions
|
|
|
|||
|
Storage
|
|
Supports T-Flash card(max supports 256GB); Cloud Storage； NVR；NAS
|
|
|
|||
|
Alarm detection
|
|
Supports Motion detection; Humanoid detection; Humanoid tracking; LED light Timing ON & OFF
|
|
|
|||
|
Rated voltage
|
|
DC12V±5%
|
|
|
|||
|
Power consumption
|
|
Rated power：5W (with IR LED lights ON)/Max power：11W (with Pan & Tilt ON)
|
|
|
|||
|
Operating condition
|
|
Temperature: -10～50℃; Humidity: ＜90%
|
|
|
|||
|
Weight
|
|
Net: 472g（Note: in kind prevail）
|
|
|
|||
|
Box size
|
|
180x160x125mm
|
|
|
|||
|
Carton
|
|
64.5x38x33.5cm
|
|
|
|||
|
PCS/CTN
|
|
20
|
|
|
|||
