Quick Details
Quick Details
-
Place of Origin:
-
China
-
Weight (KG):
-
300 KG
-
Material of Pipe:
-
PTFE
Product Description
Main Feature
Application：
* Shielding for wire and cable products
* Sanitary hose (Plumbing hose) product
* Teflon hose
* Low pressure hose and high pressure hose
* Irony steam hose
* Refrigerating fluid charge hose
* Hydraulic hose
* Sanitary hose (Plumbing hose) product
* Teflon hose
* Low pressure hose and high pressure hose
* Irony steam hose
* Refrigerating fluid charge hose
* Hydraulic hose
Braiding Material :
* Stainless steel wire (0.10-0.35mm)
* Nylon wire
* Alumium wire (0.15-0.30mm)
* Carbon steel
* Polyester yarn
* Cotton yarn
* Aramid fiber
* Nylon wire
* Alumium wire (0.15-0.30mm)
* Carbon steel
* Polyester yarn
* Cotton yarn
* Aramid fiber
Technical Features：
*
Core centralizing unit
* Individual carrier tension control
* Operating speeds:
* 16 Carrier 55 rpm 24 Carrier 50 rpm
* Individual carrier tension control
* Operating speeds:
* 16 Carrier 55 rpm 24 Carrier 50 rpm
36 Carrier 36 rpm
48 Carrier 20 rpm
* Gear driven take-off for accurate control
* Braid patterns (2 over 2, and 1 over 1)
* Inverter motor drive for controlled acceleration and deceleration
* Adjustable traverse mechanism to accommodate reel variation
* Digital production counter
* Braid patterns (2 over 2, and 1 over 1)
* Inverter motor drive for controlled acceleration and deceleration
* Adjustable traverse mechanism to accommodate reel variation
* Digital production counter
Options：
*
Empty bobbin detector
* Central lubrication system (recommended)
* Enhanced Sound Enclosure
* Keel lubricator (recommended)
* Advance display, variable speed
* Longitudinal tape applicator
* Motor driven capstan(speed reducer capstan )
* Single deck( Double Deck) Braiding System
* Central lubrication system (recommended)
* Enhanced Sound Enclosure
* Keel lubricator (recommended)
* Advance display, variable speed
* Longitudinal tape applicator
* Motor driven capstan(speed reducer capstan )
* Single deck( Double Deck) Braiding System
Specification
|
|
GLT 16L-114B
|
GLT
24L-114B
|
GLT
36L-114B
|
GLT
48L-114B
|
|||
|
Motor power
|
0.75kw
|
1.1kw
|
1.5kw
|
2.2kw
|
|||
|
Voltage
|
3 Phase 380V
Customized |
3 Phase 380V
Customized |
3 Phase 380V
Customized |
3 Phase 380V
Customized |
|||
|
Spindle RPM
|
55RPM
|
45RPM
|
36RPM
|
20RPM
|
|||
|
Traction RPM
|
5.26-26RPM
|
4.26-18.5RPM
|
2.13-10.8RPM
|
0.13-0.58RPM
|
|||
|
Take Up Reel
|
Attachment
|
Attachment
|
Charge for take up reel
|
Charge for take up reel
|
|||
|
Hose Diameter
|
≤16mm
|
≤24mm
|
≤36mm
|
≤48mm
|
|||
|
Traction Gear
|
200
|
200
|
800
|
800
|
|||
|
Spindle NO
|
16 Spindle
|
24Spindle
|
36Spindle
|
48Spindle
|
|||
|
Weight
|
280kg
|
305kg
|
680kg
|
480kg
|
|||
|
Bobbin Size
|
Out edge 56× Inner edge 22×High170mm Cubage:354cm3
|
|
|
|
|||
|
Apply
|
Change spindle can braiding wire and yarn
|
|
|
|
|||
|
Dimenson
|
620*500*1580mm
|
890*720*1680mm
|
1100*1000*1780mm
|
1500*1300*2100mm
|
|||
