Quick Details
-
Material:
-
Aluminum shell semi-sealed
-
Function:
-
Burnout Protection
-
Brand Name:
-
Mitu
-
Model Number:
-
XYM600W Black
-
Input voltage and current:
-
220V/3A
-
output voltage and current:
-
12V/30A, 24V/20A, 36V/15A, 48V/10A, 60V/8A, 72V/5A
-
Maximum Output Power:
-
600W
-
Place of Origin:
-
Anhui, China
-
AC Input Voltage Range:
-
180-264VAC; 45-65Hz
-
AC input maximum current:
-
3.0A@220VAC
-
Machine efficiency:
-
≥90.0%
-
Noise:
-
≤45dB
-
Net weight:
-
2KG
-
Working temperature:
-
-10℃-45℃
-
Storage temperature:
-
-20℃-65℃
-
Size:
-
217*130*73
-
Overheating protection:
-
Yes
-
No-load protection:
-
Yes
Quick Details
-
Type:
-
Electric
-
Port:
-
DC, AC
-
Usage:
-
electric Bumper Car
-
Material:
-
Aluminum shell semi-sealed
-
Function:
-
Burnout Protection
-
Brand Name:
-
Mitu
-
Model Number:
-
XYM600W Black
-
Input voltage and current:
-
220V/3A
-
output voltage and current:
-
12V/30A, 24V/20A, 36V/15A, 48V/10A, 60V/8A, 72V/5A
-
Maximum Output Power:
-
600W
-
Place of Origin:
-
Anhui, China
-
AC Input Voltage Range:
-
180-264VAC; 45-65Hz
-
AC input maximum current:
-
3.0A@220VAC
-
Machine efficiency:
-
≥90.0%
-
Noise:
-
≤45dB
-
Net weight:
-
2KG
-
Working temperature:
-
-10℃-45℃
-
Storage temperature:
-
-20℃-65℃
-
Size:
-
217*130*73
-
Overheating protection:
-
Yes
-
No-load protection:
-
Yes
Specification
Product Description
Safety
The application of dual-tube forward technology; reliable hardware protection and voltage and current self-check protection; perfect charging strategy. Make sure the charging process is highly safe.
Reliable
The shell adopts an integrated extrusion structure; the inside of the machine adopts a glue filling process; the active cooling fan adopts a long-life, potting structure design. With highly reliable product engineering design and years of industry verification, the charger can adapt to harsh environments.
Function
With battery activation function, three-color indicator light can be connected externally; charging lock (the vehicle power system can be locked through the relay dry contact during the charging process). Meet the charging needs of various occasions.
Overheating protection
: When the internal temperature of the charger exceeds the internal set value, the charging current will automatically decrease; if the ambient temperature exceeds 65°C, the charger will shut down for protection, and automatically resume charging when the temperature recovers.
Battery reverse connection protection
: When the battery is reversely connected, the internal circuit of the charger is disconnected from the battery, which will not damage the charger.
No-load protection
: no output when no battery is connected.
Short-circuit protection
: When the output is short-circuited, the internal circuit of the charger is disconnected from the battery, and charging can be resumed only when the battery is reconnected after the fault is eliminated.
Automatic shutdown when fully charged
: automatically shutdown when fully charged.
