Quick Details
-
After-sales Service Provided:
-
Video technical support
-
Place of Origin:
-
Shandong, China
-
Name:
-
poultry chicken house fan
-
Advantage:
-
Intelligent control
-
Power controller:
-
Chnt or Schneider
-
Servie Life:
-
More than 20 years
-
Service:
-
Chicken house design and equipment install
-
Feed line:
-
3pan/3m, 4pan/3m
-
Model Number:
-
UBT poultry chicken house fan
Quick Details
-
Applicable Industries:
-
Farms
-
Mounting:
-
Wall Fan
-
Power:
-
1.1-1.5kw
-
After-sales Service Provided:
-
Video technical support
-
Place of Origin:
-
Shandong, China
-
Name:
-
poultry chicken house fan
-
Advantage:
-
Intelligent control
-
Power controller:
-
Chnt or Schneider
-
Servie Life:
-
More than 20 years
-
Service:
-
Chicken house design and equipment install
-
Feed line:
-
3pan/3m, 4pan/3m
-
Model Number:
-
UBT poultry chicken house fan
long life span poultry farm chicken house ventilation fan
(U-BEST)
Ventilation System:
This system including Butterfly Cone Fan ,Centrifugal Exhaust Fan ,Air Inlet Window, controls the climate conditions,humidity and temperature in poultry shed and supply fresh air.
(1) Butterfly Cone Type P oultry Exhaust Fan :
| Parameters Of Butterfly Cone Fans | |||||||||
| Model |
Blade Diameter (mm) |
Blade Speed (rpm) |
Moter Speed (rpm) |
Air Flow (m³/h) |
Total Pressure (pa) |
Noise (db) |
Input Power (w) |
Rated Voltage (v) |
High/Width xThickness (mm) |
| DJF(c)-900(30") | 750(30") | 630 | 1400 | 22000 | 65 | ≤65 | 370 | 380 | 900x 1050 |
| DJF(c)-1100(40") | 1000(39") | 600 | 1400 | 32500 | 70 | ≤70 | 750 | 380 | 1100 x 1280 |
| DJF(c)-1220(43") | 1100(43") | 460 | 1400 | 38000 | 73 | ≤70 | 750 | 380 | 1220 x 1280 |
| DJF(c)-1380(50") | 1250(50”) | 439 | 1400 | 44000 | 80 | ≤70 | 1100 | 380 | 1380 x 1480 |
(2)Centrifugal Type Poultry Exhaust Fan:
| Parameters Of Centrifugal Fans | |||||||||
| Model |
Blade Diameter (mm) |
Blade Speed (rpm) |
Moter Speed (rpm) |
Air Flow (m³/h) |
Total Pressure (pa) |
Noise (db) |
Input Power (w) |
Rated Voltage (v) |
High x Width xThickness (mm) |
| DJF-750 | 600(24") | 960 | 960 | 10600 | 75 | ≤70 | 370 | 380 | 750 x 750 x 510 |
| DJF-1000 | 910(36") | 438 | 1400 | 21000 | 57 | ≤65 | 550 | 380 | 1000 x 1000 x 450 |
| DJF-1380 | 1270(50") | 437 | 1400 | 44000 | 57 | ≤65 | 1100 | 380 | 1380 x 1380 x 450 |
(3) Air inlet
Control device for air inlet window
* Automatic control : As the request of difference chicken house pressure by the controller control ,
make the air inlet window open and off automatically , to meet the request.
* Manual control: Operator will check the pressure of chicken house , control the winch by hand until
meet the request.
Air inlet window parameters
* The wall of installed windows must keep the same level.
* Within 15cm below the window must be solid wall which could be fixed with expansion bolt ,hollow
brick not available.
* To prevent water flow backward , the window hole inside is higher than outside.
* Pre-embedded wood frame is same level with inside wall fo chicken house.
Related Products:
1 Environment controller
Under the controller including T607 / T606 or IMAGE II , it could save the labor and reach a most advanced control
2 Main Feed Line System
The feed can be conveyed from the silo or manpower hopper into each feeding line
3 Pan Feeding Line System
This system convey feed from silo/hopper to feeder pan . There is a feed sensor at the end of each feeding line to achieve automatic feed delivery
4 Automatic Nipple Drinking Line
Main part of the system:filter,pressure regulator, doser,nipple drinking line.Lifting and suspension system,electric shock system
5 Cooling Pad System
It is the most economical and effective way to reduce temperature of chicken house in summer
6 Heating System
This system including hot blast heater(fuel or diesel or coal), infrared gas brooder,
poultry gas heater and etc.
