Quick Details
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Suntree
-
Model Number:
-
pv-cable
-
Core:
-
Single Core, Twins Core
-
Insulation:
-
XLPE,2PFG 1169, Dual wall insulation,electron beam cross-linked
-
Resist:
-
UV Resist,abrasion Resist, water,ozone,fluids,salt,general weathering
-
Cross section:
-
1.5mm2, 2.5mm2, 4mm2, 6mm2,10mm2
-
Rated Current:
-
20A,30A,50A
-
Color:
-
Black or Red
-
Rated Voltage:
-
AC/DC 1000V/800V
-
Wire:
-
Class 5, Tinned
-
Packing:
-
Standard Packing
Quick Details
-
Application:
-
solar system
-
Conductor Material:
-
Copper
-
Conductor Type:
-
Stranded
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Suntree
-
Model Number:
-
pv-cable
-
Core:
-
Single Core, Twins Core
-
Insulation:
-
XLPE,2PFG 1169, Dual wall insulation,electron beam cross-linked
-
Resist:
-
UV Resist,abrasion Resist, water,ozone,fluids,salt,general weathering
-
Cross section:
-
1.5mm2, 2.5mm2, 4mm2, 6mm2,10mm2
-
Rated Current:
-
20A,30A,50A
-
Color:
-
Black or Red
-
Rated Voltage:
-
AC/DC 1000V/800V
-
Wire:
-
Class 5, Tinned
-
Packing:
-
Standard Packing
Product Description
(1) Dual wall insulation,Electron beam cross-linked.
(2) Resistance to UV,water,ozone,fluids,salt,general weathering.
(3) Halogen free,flame,retardant,low toxicity.
(4) Flexibility and stripping performance.
(5) TUV approved.
(6) High current carrying capacity.
(7) Resistance to abrasion.
(2) Resistance to UV,water,ozone,fluids,salt,general weathering.
(3) Halogen free,flame,retardant,low toxicity.
(4) Flexibility and stripping performance.
(5) TUV approved.
(6) High current carrying capacity.
(7) Resistance to abrasion.
Product parameters
|
Single Core
|
Cross section mm²
|
Strand design No.x ø(mm)
|
Conductor diameter mm
|
Conductor diameter Ω /km
|
Outer diameter mm
|
|
PV-1*1.5 mm²
|
1.5
|
30x ø 0.25
|
1.6
|
13.9
|
4.5
|
|
PV-1*2.5 mm²
|
2.5
|
48x ø 0.25
|
2.0
|
8.06
|
5.3
|
|
PV-1*4.0 mm²
|
4.0
|
56x ø 0.3
|
2.6
|
4.97
|
6.2
|
|
PV-1*6.0 mm²
|
6.0
|
81x ø 0.3
|
3.3
|
3.52
|
7.2
|
|
PV-1*10.0 mm²
|
10.0
|
200x ø0.25
|
4.4
|
2.12
|
8.3
|
|
PV-1*16 mm²
|
16.0
|
224x ø 0.3
|
5.2
|
1.95
|
9.5
|
|
