Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
KCGF
-
Weight:
-
700 KG
-
Power:
-
30 KW
-
Machine structure:
-
Double sides, single layer, outer yarn thread pneumatically
-
Number of spindles:
-
10n, 80 spindles are standard
-
Spindle gauge:
-
Basic 400mm, others can be selected
-
Single spindle drive motor:
-
500W/spindle
-
Twist range:
-
120-800 T/M ( Need to be selected )
-
Traverse:
-
150mm-250mm
-
Rated power:
-
30 KW
-
Take-up package:
-
Max. 8kg
-
Spindle tensioner:
-
Magnetic tensioner
-
Take-up speed:
-
Max. 80 m/min
Quick Details
-
Marketing Type:
-
New Product 2023
-
Application:
-
twisting nylon yarn polyester yarn
-
Production Capacity:
-
800 sets per year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
KCGF
-
Weight:
-
700 KG
-
Power:
-
30 KW
-
Machine structure:
-
Double sides, single layer, outer yarn thread pneumatically
-
Number of spindles:
-
10n, 80 spindles are standard
-
Spindle gauge:
-
Basic 400mm, others can be selected
-
Single spindle drive motor:
-
500W/spindle
-
Twist range:
-
120-800 T/M ( Need to be selected )
-
Traverse:
-
150mm-250mm
-
Rated power:
-
30 KW
-
Take-up package:
-
Max. 8kg
-
Spindle tensioner:
-
Magnetic tensioner
-
Take-up speed:
-
Max. 80 m/min
It is applied to make twisting of nylon yarns, polyester yarns, tire cods, various industrial yarns and carpet yarns.
Features
1. Low energy consumption: It can greatly reduce power consumption per unit production (environmentally friendly motor or apron belt drive is optional for each spindle);
2. Convenient adjustment on tension: it's equipped with flexible and stable tensioner inside& outside, which is convenient to adjust the tension;
3. Simple operation: pneumatic threading and manual brake design for outside yarn is to reduce the intensity of workers and improve production efficiency;
4. Compact structure makes machine less occupation of space: The height of the whole machine is reasonable and considerate, which is easy to take off yarn bobbins or change yarn bobbins; This machine small occupation of space, which can improve the utilization rate of working land.
5. Reasonable composition: air duct and yarn guide channel are assigned accurately, to ensure the machine nice appearance and convenient operation.
Features
1. Low energy consumption: It can greatly reduce power consumption per unit production (environmentally friendly motor or apron belt drive is optional for each spindle);
2. Convenient adjustment on tension: it's equipped with flexible and stable tensioner inside& outside, which is convenient to adjust the tension;
3. Simple operation: pneumatic threading and manual brake design for outside yarn is to reduce the intensity of workers and improve production efficiency;
4. Compact structure makes machine less occupation of space: The height of the whole machine is reasonable and considerate, which is easy to take off yarn bobbins or change yarn bobbins; This machine small occupation of space, which can improve the utilization rate of working land.
5. Reasonable composition: air duct and yarn guide channel are assigned accurately, to ensure the machine nice appearance and convenient operation.
|
Machine structure
|
Double-sides and single layer, outer yarn thread pneumatically
|
|
Number of spindles
|
10n, 80 spindles are standard
|
|
Spindle gauge
|
Basic 400mm, other can be selected
|
|
Single spindle drive motor
|
500 W/spindle
|
|
Twist range
|
120-800 T/M ( Need to be selected )
|
|
Traverse
|
150mm-250mm
|
|
Rated power
|
30 KW
|
|
Start-up mode
|
Frequency conversion slow start
|
|
Take-up package
|
Max. 8kg
|
|
Spindle speed range
|
Max.700 r/min
|
|
Spindle tensioner
|
Magnetic tensioner
|
|
Winding motor
|
1.1 KW
|
|
Winding speed
|
Max. 80m/min
|
|
Spindle drive
|
Apron belt circulation drive, single spindle driving for option
|
