- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
AWY
-
Model Number:
-
custom(Horizontal type)
-
Item:
-
Wood chipper
-
Max. crushing diameter:
-
76mm/ 89mm/100mm
-
Engine:
-
gasoline engine OHV 4-stroke
-
Displacement:
-
196CC/390CC/420CC
-
Engine power:
-
6.5HP/13HP/15HP
-
Fuel consumption:
-
1.5L/h, 2.7L/h, 4L/h
-
Engine speed:
-
3600r/min
-
Blade speed:
-
2400rpm
-
Discharging size:
-
1-3cm
-
Productivity:
-
600-800kg/h
Quick Details
-
Grade:
-
DIY, Industrial
-
Warranty:
-
1 years
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
AWY
-
Model Number:
-
custom(Horizontal type)
-
Item:
-
Wood chipper
-
Max. crushing diameter:
-
76mm/ 89mm/100mm
-
Engine:
-
gasoline engine OHV 4-stroke
-
Displacement:
-
196CC/390CC/420CC
-
Engine power:
-
6.5HP/13HP/15HP
-
Fuel consumption:
-
1.5L/h, 2.7L/h, 4L/h
-
Engine speed:
-
3600r/min
-
Blade speed:
-
2400rpm
-
Discharging size:
-
1-3cm
-
Productivity:
-
600-800kg/h
Products Description
|
Model
|
YY500
|
YY850
|
|
Engine
|
4-stroke, air cooled gasoline engine
|
4-stroke, air cooled gasoline engine
|
|
Displacement
|
196cc
|
420cc
|
|
Power
|
6.5Hp/ 3600rpm
|
15Hp/3600rpm
|
|
Cutter speed
|
2400r/min
|
2400r/min
|
|
Max. crushing diameter
|
50mm
|
100mm
|
|
Discharging size
|
1-3cm
|
1-3cm
|
|
Productivity
|
600-800kg/h
|
>= 800kg/h
|
|
Fuel tank
|
3.6L
|
6.5L
|
|
Gasoline type
|
90#/93#/97#
|
Unleaded gasoline
|
|
Start mode
|
Manual
|
Manual/Electric
|
|
Weight
|
130kg
|
180kg
|
|
Dimension
|
95*47*91cm
|
115*68*106cm
|
Parameters are based on YY500 and YY850, the products shown below can be customized, please contact us for detailed parameters.
