Quick Details
-
Panel Size:
-
6 in/8 in / 10 in / 12 in / 15 in/ 18 in
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
GV
-
use:
-
led scoreboard
-
Display Function:
-
Number
-
Pixels:
-
6 in/8 in / 10 in / 12 in / 15 in/ 18 in/ 20 in/ 22 in/ 24 in/ 32 inch
-
Color::
-
white / red / green / yellow
-
Application::
-
gas station, score board
-
Life span::
-
100000hours
-
Function::
-
numbers display
-
power supply:
-
AC 110 V ~ 220 V , DC 5 V ~ 12 V
-
Installation::
-
Wall/ceiling mounting
-
Energy saving::
-
Illumination adjustable
-
Operation:
-
Remote contro & button
Quick Details
-
Application:
-
gas price display
-
Brand Name:
-
Grandview
-
Color:
-
white / red / green / yellow
-
Panel Size:
-
6 in/8 in / 10 in / 12 in / 15 in/ 18 in
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
GV
-
use:
-
led scoreboard
-
Display Function:
-
Number
-
Pixels:
-
6 in/8 in / 10 in / 12 in / 15 in/ 18 in/ 20 in/ 22 in/ 24 in/ 32 inch
-
Color::
-
white / red / green / yellow
-
Application::
-
gas station, score board
-
Life span::
-
100000hours
-
Function::
-
numbers display
-
power supply:
-
AC 110 V ~ 220 V , DC 5 V ~ 12 V
-
Installation::
-
Wall/ceiling mounting
-
Energy saving::
-
Illumination adjustable
-
Operation:
-
Remote contro & button
Product Description
|
LED Chips parameter
|
|
|
|
|
|
|
|
|
||||||||
|
Color
|
Brightness
|
Wave Length
|
Current
|
Operating
Voltage |
Viewing angel
|
LED
Chips size |
Color
temperature |
Luminous flux
|
||||||||
|
RED
|
4000mcd
|
620-630
|
60MA
|
1.9-2.4V
|
60°/120°
/180° |
10*20Mil
|
620-630K
|
2LM
|
||||||||
|
GREEN
|
10000mcd
|
515-525
|
|
3.0-3.4V
|
|
|
515-525K
|
3LM
|
||||||||
|
BLUE
|
8000mcd
|
515-525
|
|
2.5-3.0V
|
|
|
460-470K
|
3LM
|
||||||||
|
YELLOW
|
3500mcd
|
585-590
|
|
1.9-2.2V
|
|
|
588-595K
|
1.5LM
|
||||||||
|
WHITE
|
12000mcd
|
0
|
|
3.0-3.4V
|
|
|
6000-7000K
|
5LM
|
||||||||
|
SERIES PARAMETERS
|
|
|
|
|
|
|
|
|||||||
|
Item
|
Technical Parameters
|
|
|
|
|
|
|
|||||||
|
Color:
|
Red, Amber, Green, Blue, White
|
|
|
|
|
|
|
|||||||
|
Digit Height:
|
6'', 8'', 10'', 12'', 15'', 18'', 20'', 22'', 24'', 32'', 64'', 72''
|
|
|
|
|
|
|
|||||||
|
Digit Design:
|
7 segments modules are sealed with glue,reach IP67 waterproof grade,with
dust shade that make leds work normally all the time. |
|
|
|
|
|
|
|||||||
|
Brightness Control:
|
Auto dimming by brightness sensor
|
|
|
|
|
|
|
|||||||
|
Display Dimming:
|
Over 8 levels of automatic intensity adjustment
|
|
|
|
|
|
|
|||||||
|
Viewing Angle:
|
Horizontal:60°-120°,Vertical: 60°-120° or customized
|
|
|
|
|
|
|
|||||||
|
Service Access:
|
Front or rear open
|
|
|
|
|
|
|
|||||||
|
Master/slave:
|
Single sided or double sided, master/slaves available
|
|
|
|
|
|
|
|||||||
|
Cabinet Material:
|
Iron cabinet or aluminum alloy frame
|
|
|
|
|
|
|
|||||||
|
Waterproof Level:
|
IP53 with aluminum alloy frame, IP65 with iron cabinet
|
|
|
|
|
|
|
|||||||
|
Led Driving Mode:
|
Constant current
|
|
|
|
|
|
|
|||||||
|
Power Input:
|
110/220V AC,50-60HZ
|
|
|
|
|
|
|
|||||||
|
PC Communication:
|
RS232/485;LAN(TCP/IP) with cables or wireless,customer can choose
|
|
|
|
|
|
|
|||||||
|
Communication Distance:
|
Max.15 meters for RS232, 1200 meters for RS485
|
|
|
|
|
|
|
|||||||
|
Remote Control Type:
|
RF remote control (Normal 6 buttons or LCD remote controller)
|
|
|
|
|
|
|
|||||||
|
Continuous Working Time:
|
Unlimited
|
|
|
|
|
|
|
|||||||
|
Lifetime of Leds:
|
>100,000 hours
|
|
|
|
|
|
|
|||||||
|
Installation Method:
|
Hanging,mounting or per custom design
|
|
|
|
|
|
|
|||||||
|
Working Temperature:
|
-40℃~75℃
|
|
|
|
|
|
|
|||||||
|
Display Format:
|
8.88, 8.888,8.888, 8.889/10, 88.88, 88.888 etc.
|
|
|
|
|
|
|
|||||||
Customized according to your needs .
