• Flexible-installing & Easy-handling.
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25
-
Brand Name:
-
Jinko
-
Model Number:
-
JKM54HL4R-B
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1762*1134*30mm
-
Place of origin:
-
China(Jiangsu)
-
Brand name:
-
Trina
-
size:
-
1762*1134*30mm
-
Product name:
-
Jinko Solar Panel
-
Frame:
-
30mm Anodized aluminium alloy
-
Backsheet:
-
White
-
Solar cells:
-
Monocrystalline
-
Cell Orientation:
-
108 cells
-
Weight:
-
22kg
-
Connector:
-
TS4 / MC4 EVO2*
-
Certificate:
-
IEC/ISO/UL
Quick Details
-
Cell size:
-
210mmx210mm
-
Type:
-
PERC, Half Cell, IBC, HJT, hbc, Flexible, BIPV, Double-glass, MWT, N-TYPE, Bifacial
-
Panel Efficiency:
-
22.02%
-
Warranty:
-
25
-
Brand Name:
-
Jinko
-
Model Number:
-
JKM54HL4R-B
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1762*1134*30mm
-
Place of origin:
-
China(Jiangsu)
-
Brand name:
-
Trina
-
size:
-
1762*1134*30mm
-
Product name:
-
Jinko Solar Panel
-
Frame:
-
30mm Anodized aluminium alloy
-
Backsheet:
-
White
-
Solar cells:
-
Monocrystalline
-
Cell Orientation:
-
108 cells
-
Weight:
-
22kg
-
Connector:
-
TS4 / MC4 EVO2*
-
Certificate:
-
IEC/ISO/UL
Product Description
|
Peak Power Watts(Wp)*
|
420
|
425
|
430
|
435
|
440
|
|
Maximum Power Voltage Range(V)
|
32.16
|
32.37
|
32.58
|
32.78
|
32.99
|
|
Maximum Power Current(A)
|
13.06
|
13.13
|
13.20
|
13.27
|
13.34
|
|
Open Circuit Voltage(V)
|
38.74
|
38.95
|
39.16
|
39.36
|
39.57
|
|
Short Circuit Current(A)
|
13.51
|
13.58
|
13.65
|
13.72
|
13.80
|
|
Module Efficiency(%)
|
21.02
|
21.27
|
21.52
|
21.77
|
22.02
|
• Flexible-installing & Easy-handling.
Small in size, big on power
Based on advanced technology from the Vertex platform. The upgrade Vertex S 420
W module is up to 440W, 22.0% module efficiency with high density interconnect technology. It is perfectly designed to fulfill power, efficiency, size, weight, appearance,mechanical load, reliability requirements of rooftop application! Best balance of power and size & weight.
Product Workmanship Warranty
25 Years
Performance Warranty
Product diagram
Why Choose Us
100% Cells Sorting
Ensure Colour and Power Difference.
Ensure high yields,consistent performance and durability,
First of 52 steps strict quality control and inspection process.
Before and After Lamination.
Most stringent acceptance criteria and tightest tolerance,
Intelligent alarm and stop mechanism in case of any deviation or errors.
Before and Following Lamination
Ensure "Zero" micro crack monitoring before final inspection, Continuous line monitoring and video/photo record for each cell and
panel
100% "Zero"
Defects Objective Before Shipment.
Most stringent acceptance criteria and tightest tolerance,
Ensure the best modules on the market- guaranteed!
Defects Objective Before Shipment.
Most stringent acceptance criteria and tightest tolerance,
Ensure the best modules on the market- guaranteed!
Ensure 3% Positive Power Tolerance
Comprehensive QC information management system with barcode ID.Quality traceable system in place to allow quality data flow
constantly.
Our factory
FAQ
Q1: How to choose a right system and products?
A1:Tell us your requirements, then our seller will recommend a suitable product and system to you.
Q2: The advantages of home photovoltaic system
A2: Solar photovoltaic power generation performance is stable and reliable, with a service life of more than 25 years;Small investment, big income;zero pollution;Low maintenance costs;
Q3: Why choose us?
A3:Our company has been engaged in new energy power generation for more than 20 years. Our products and services cover more than 60 countries. Our R&D team is composed of top experts in various fields. We are committed to providing first-class solutions for PV power plants.
Q4: What is the warranty of solar system?
A4: 5 years for whole system,10 years for inverter,modules,frame.And we can make sure our products will through very strictly testing,and then send to you.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
Q6:What about the package?
A6: Bind them in wooden cases or wrap them in cartons
A1:Tell us your requirements, then our seller will recommend a suitable product and system to you.
Q2: The advantages of home photovoltaic system
A2: Solar photovoltaic power generation performance is stable and reliable, with a service life of more than 25 years;Small investment, big income;zero pollution;Low maintenance costs;
Q3: Why choose us?
A3:Our company has been engaged in new energy power generation for more than 20 years. Our products and services cover more than 60 countries. Our R&D team is composed of top experts in various fields. We are committed to providing first-class solutions for PV power plants.
Q4: What is the warranty of solar system?
A4: 5 years for whole system,10 years for inverter,modules,frame.And we can make sure our products will through very strictly testing,and then send to you.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
Q6:What about the package?
A6: Bind them in wooden cases or wrap them in cartons
