Quick Details
-
Applicable Industries:
-
Other
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Gongle
-
Dimension(L*W*H):
-
115*115*95CM
-
Weight (KG):
-
65 KG
-
Product name:
-
evaporative air cooler
-
Key Selling Points::
-
Competitive Price
-
Mounting::
-
Wall / Window/ roof / free standing with wheel
-
Cooling pad::
-
four sides,7090 or 5090 cooling pad
-
voltage::
-
220V 380v 415v or customized
-
Motor power::
-
1.1kw /1.5kw/2.2/3/4KW
-
Wind::
-
18000/ 25000/ 30000/40000/50000m3/h
-
Power::
-
1.1/ 1.5/2.2/3/4/5Kw
-
speed::
-
510r/min
-
Keyword:
-
industrial air conditioners
Quick Details
-
Type:
-
EVAPORATIVE AIR COOLER
-
Mounting:
-
Wall / Window Mount
-
Airflow:
-
18000m³/h 25000m³/h 30000m³/h 40000m³/h
-
Applicable Industries:
-
Other
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Gongle
-
Dimension(L*W*H):
-
115*115*95CM
-
Weight (KG):
-
65 KG
-
Product name:
-
evaporative air cooler
-
Key Selling Points::
-
Competitive Price
-
Mounting::
-
Wall / Window/ roof / free standing with wheel
-
Cooling pad::
-
four sides,7090 or 5090 cooling pad
-
voltage::
-
220V 380v 415v or customized
-
Motor power::
-
1.1kw /1.5kw/2.2/3/4KW
-
Wind::
-
18000/ 25000/ 30000/40000/50000m3/h
-
Power::
-
1.1/ 1.5/2.2/3/4/5Kw
-
speed::
-
510r/min
-
Keyword:
-
industrial air conditioners
Advantages of industrial air conditioners air cooler with good price
1)Four sides cooling pad,evaporative cooling,covering an area of 150 m2.
2)High efficiency for cooling,no noise.
3)Don't need all enclosed.
4)Popular cooling products.Size:1140*1140*950mm.
5) Environmental ,Ventilation, Health - Use natural water cooling .
1. Multiple Function: Air cooler, Fan, Purifier and Humidifier.
2. Honeycomb wet pad for optimum performance, which provides the largest contact area.
3. Adjustable air level to your comfort.
4. Mounted with castors for easy mobility.
5. Simple operation and good appearance.
6. Over current and overvoltage protection.
|
Specifications
|
Model GL-18000
|
Model GL-25000
|
Model GL-30000
|
|
Air capacity
|
18000m3/h
|
25000m3/h
|
30000m3/h
|
|
Covering area
|
120-150m2
|
150-500m2
|
150-200m2
|
|
Fan type
|
Axial fan
|
Axial fan
|
Axial fan
|
|
Motor
|
1.1/1.5kw
|
2.2kw
|
3kw
|
|
Voltage
|
380/220v,50hz
|
380v,50hz
|
380v,50hz
|
|
Noise level
|
<71dB
|
<75db
|
<75db
|
|
Evaporative efficiency
|
85-90%
|
85-90%
|
85-90%
|
|
Water consumption
|
10-15L/H
|
10-15L/H
|
40L/H
|
|
Unit weight
|
52kg
|
80kg
|
120kg
|
|
Cooling pad
|
5090/7090
|
5090/7090
|
5090/7090
|
|
Duct size
|
670*670mm
|
670*670mm
|
800*800mm
|
|
Frame dimension
|
1100*1100*950mm
|
1150*1150*1150mm
|
1250*1250*1250mm
|
|
Guarantee
|
1 year
|
1 year
|
1 year
|
Chinese big volume industrial evaporative air cooler
Spare parts specifications of Chinese big volume industrial evaporative air cooler
1) Shell: high quality engineering plastic PP,corrosion resistance,with long service life,
2) Motor: Professional design for air cooler, high efficiency, low noise, big power, Chassis adopts tensile aluminum, light weight, heat faster.
folding and corrosion.
4) Cooling Pad :7090 or 5090 model or with one side balck coated ,the Swedish technology manufacturing, blisters, not deformation, evaporation temperature effect is obvious, at the same time produce a large number of negative oxygen ions, effective increase the oxygen in the air.
5) Water Pump: Exclusive used water pump for air cooler, long life, large water quantity , super-quiet operation, energy saving efficiency
6) Drain Valve: can be with hand control or automatic drain valve, can exclude the water from the tank automatically, get good cleaning effect.
Details of
Chinese big volume industrial evaporative air cooler
|
The installation of the air cooler for up down and side discharge
|
Widely application of
Chinese big volume industrial evaporative air cooler
1)Any Industrial (Texitle, Garment, Plastic, Ceramic etc).
2)Commercial (shopping mall, restaurant, parties etc).
3)House, villas, office ect.
4)Coporation countries: South Africa ,Algeria ,Philippines ,Thailand, Australia, Brazil ,Romania, Cyprus, Africa, Middle East ,etc .
