- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
LB2822
-
Max. Current:
-
20A
-
Product name:
-
LB2822
-
Color:
-
Red Green Blue
-
Function:
-
ON-OFF-ON
-
Application:
-
Marine Equipment
-
Mechanical Life:
-
300,000 Cycles
-
Button color:
-
Gold/Silver/Black
-
Electrical Life:
-
50000times
-
Size:
-
28*22mm
-
Type:
-
Rocker switch
-
Voltage:
-
250VAC
Quick Details
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LANBOO
-
Model Number:
-
LB2822
-
Max. Current:
-
20A
-
Product name:
-
LB2822
-
Color:
-
Red Green Blue
-
Function:
-
ON-OFF-ON
-
Application:
-
Marine Equipment
-
Mechanical Life:
-
300,000 Cycles
-
Button color:
-
Gold/Silver/Black
-
Electrical Life:
-
50000times
-
Size:
-
28*22mm
-
Type:
-
Rocker switch
-
Voltage:
-
250VAC
| Mounting Aperture | 28*22mm |
| Serial Number | CX Ship type metal switch |
| Head Shape | Rocker |
| Switch Combination |
2NO2NC,Slow action double contact
gear:3-3 gears |
|
Waterproof Level |
IP65,IK10(Refer to GB/T 20138) |
| Heating Current | Ith:20A 250VAC |
| Working Environment | -40°C~+80°C (Non-vacuum state, without icing) |
| Insulation Resistance | ≥1000MΩ |
| Contact Resistance | ≤50mΩ |
| LED Voltage | 9-24V,220V |
| Rated Current | Resistive Load:AC-15:110V/220V:15A DC-13:12V/24:15A |
| Inductive Load | AC-15:110V/220V:4A DC-13/110V:4A |
| Glow Color | Red, Green, Blue / Custo Mized: Yellow, White |
