Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
BBN Steel
-
Application:
-
construction, bridge, machinery
-
Width:
-
≤4200mm
-
Length:
-
≤18000mm
-
Product Name:
-
Steel plate S275JR
-
Surface:
-
Black or coated
-
Sand blasting standard:
-
SA2.5
-
Inspection report:
-
SGS, BV, etc
-
Price Term:
-
EX-WORK/FOB/CFR/CIF
-
Shape:
-
Steel coil/sheet/plate/flat bar
-
Mill test certificate:
-
EN10204 3.1/3.2
-
Model Number:
-
EN10025-2 S275JR
-
Special Use:
-
welding structures
Quick Details
-
Type:
-
Steel Sheet
-
Standard:
-
EN
-
Grade:
-
S275JR
-
Place of Origin:
-
China
-
Brand Name:
-
BBN Steel
-
Application:
-
construction, bridge, machinery
-
Width:
-
≤4200mm
-
Length:
-
≤18000mm
-
Product Name:
-
Steel plate S275JR
-
Surface:
-
Black or coated
-
Sand blasting standard:
-
SA2.5
-
Inspection report:
-
SGS, BV, etc
-
Price Term:
-
EX-WORK/FOB/CFR/CIF
-
Shape:
-
Steel coil/sheet/plate/flat bar
-
Mill test certificate:
-
EN10204 3.1/3.2
-
Model Number:
-
EN10025-2 S275JR
-
Special Use:
-
welding structures
“S” is short for structural steel;
“275” refers to the minimum yield strength (MPa) for the steel thickness ≤ 16mm;
“JR” indicates the quality grade related to charpy impact test energy values (27J, tested at room temperature 20℃);
1.0044 is the steel number of S275JR.
| Thickness(mm) | C | Mn | P | S | N | Cu |
| T≤16 | 0.21 | 1.5 | 0.035 | 0.035 | 0.012 | 0.55 |
| 16<T≤40 | 0.21 | |||||
| 40<T | 0.22 |
| Grade | Minimum yield strength Reh | Tensile strength Rm | ||||||||||||
| MPa | MPa | |||||||||||||
| Nominal thickness | Nominal thickness | |||||||||||||
| mm | mm | |||||||||||||
| ≤16 | >16 | >40 | >63 | >80 | >100 | >150 | >200 | >250 | <3 | >3 | >100 | >150 | >250 | |
| ≤40 | ≤63 | ≤80 | ≤100 | ≤150 | ≤200 | ≤250 | ≤400 | ≤100 | ≤150 | ≤250 | ≤400 | |||
| S275JR | 275 | 265 | 255 | 245 | 235 | 225 | 215 | 205 | - | 430-580 | 410-560 | 400-540 | 380-540 | - |
| Minimum elongation - A | Notch impact test | ||||||
| Lo = 5,65 * √So (%) | |||||||
| Nominal thickness | Temperature |
Min. absorbed
energy |
|||||
| mm | |||||||
| >3 | >40 | >63 | >100 | >150 | >250 | °C | J |
| ≤40 | ≤63 | ≤100 | ≤150 | ≤250 | ≤400 | ||
| 23 | 22 | 21 | 19 | 18 | - | 20 | 27 |
Steel plate S275JR has huge usage for the structural building, manufacturing in the plant, machinery building, and in mining. Steel plate S275JR is very versatile common mild steel/carbon steel plate for multiple structural applications e.g. manufacturing plant, machinery, mining equipment and vehicles, excavators, loader, bulldozers, crane, mining hydraulic supports, construction, power plant, port equipments, drilling rigs, etc.
| EU | Germany | Japan | France | European old | Italy | China | Austria | Norway | Russia | Inter | Portugal | India |
| EN | DIN,WNr | JIS | AFNOR | EN | UNI | GB | ONORM | NS | GOST | ISO | NP | IS |
| S275JR | RSt42-2 | SS400 | E28-2 | Fe430B | Fe430B | Q275 | St42F | NS12142 | St4ps | E275B | FE430-B | IS2062 |
| St 44-2 | St430B | St4sp |
1. Certificates: ISO, API, BIS, TUV, ABS, BV, LR, DNV GL, CCS, RMRS, RINA, etc.
2. Third Party Inspection: SGS, BV, Intertek; ABS,LR, DNV GL, NK, CCS, RMRS, RINA, KR.
3. Available Test: UT, MT, Impact Test, PWHT, etc.
4. Specification limit is matchless in China even in the World, typical examples:
The Min. thickness for shipbuilding steel plates is 3mm.
The Min. thickness for hot rolled steel plates is 0.6mm.
The Max. width for pressure vessel steel plates: exceeds 5000mm.
5. Lifetime warranty: BBN steel ensure to return and replace the steel p roducts for free in its lifetime due to quality issues.
Q: Are you manufacturer or trader?
A: BBN steel is steel plate manufacturer.
We also has warehouse near Tianjin and Shanghai port. Abundant steel stocks can meet urgent demands of clients.
Q: Can you provide EN10204 3.2 MTC?
A: Yes.
Q: Can we get sample?Any charges?
A: Yes,you can get available samples in our stock. Free for real samples, but customers need to pay the freight cost.
Q: How can we get the offer?
A: Pease submit the required steel grade, size, quantity. And we will check price for you at the first time.
Q: What's your payment terms?
A: 30% down payment by T/T and 70% balance by T/T or L/C.
Q: What's your delivery time?
A: 15-45 days after receiving the down payment or L/C.
Q: Can you cut the steel plates to small pieces and drilling according to my drawing?
A: Yes. BBN Steel also provides steel machining: Grinding, Welding, Planing, Rolling, Punching, Milling, Cutting, Drilling, Turning.
