Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CSOT
-
Model:
-
HV320WHB-N5M
-
Pixel Format:
-
1366(RGB)*768 (WXGA) 49PPI
-
Size:
-
32inch
-
Frame Rate:
-
60HZ
-
Contrast Ratio:
-
1200:1 (Typ.) (TM)
-
Signal Type:
-
LVDS (2 ch, 8-bit) , 51 pins Connector
-
Display Colors:
-
16.7M
-
Response Time:
-
8 (Typ.)(G to G)
-
Lamp Type:
-
No B/L
Quick Details
-
Type:
-
TFT
-
Display Size:
-
32inch
-
Supplier Type:
-
Original manufacturer
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CSOT
-
Model:
-
HV320WHB-N5M
-
Pixel Format:
-
1366(RGB)*768 (WXGA) 49PPI
-
Size:
-
32inch
-
Frame Rate:
-
60HZ
-
Contrast Ratio:
-
1200:1 (Typ.) (TM)
-
Signal Type:
-
LVDS (2 ch, 8-bit) , 51 pins Connector
-
Display Colors:
-
16.7M
-
Response Time:
-
8 (Typ.)(G to G)
-
Lamp Type:
-
No B/L
Product specifications
|
Panel Brand
|
BOE
|
Panel Model
|
HV320WHB-N5M
|
||
|
Panel Size
|
32.0"
|
Panel Type
|
a-Si TFT-LCD , CELL
|
||
|
Resolution
|
1366(RGB)×768, WXGA, 49PPI
|
Pixel Format
|
RGB Vertical Stripe
|
||
|
Display Area
|
697.685(W)×392.256(H) mm
|
Bezel Opening
|
-
|
||
|
Brightness
|
0 cd/m²
|
Contrast Ratio
|
1200:1 (Typ.) (TM)
|
||
|
Viewing Angle
|
89/89/89/89 (Typ.)(CR≥10)
|
Display Mode
|
ADS, Normally Black, Transmissive
|
||
|
Best View on
|
Symmetry
|
Response Time
|
8 (Typ.)(G to G)
|
||
|
Display Colors
|
16.7M
|
Lamp Type
|
No B/L
|
||
|
Frequency
|
-
|
Touch Screen
|
Without
|
||
|
Panel Weight
|
-
|
Application
|
|
||
|
Environment
|
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
|
|
|
||
