CPCD15: Load capacity 1500kg,hydraulic transmission,3m 2stage duplex mast,
China engine C490BPG,1070mm fork, Electronic gear transmission, key switch,
Pneumatic tyres,Safety seat,Free tool box and spare parts.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Top Brand
-
Fork Length:
-
920mm
-
Fork Width:
-
100mm, 100-175mm
-
Overall Dimensions:
-
2245*1070*2070mm
-
Weight (KG):
-
2780 kg
-
Certification:
-
CE, ISO
-
Min.ground clearance:
-
110mm
-
Engine power:
-
34.5/2500
-
Free lift height(standard):
-
170mm
-
Height of Load-backrest:
-
995mm
-
Fuel tank capacity:
-
60L
Quick Details
-
Min. Lifting Height:
-
3m
-
Warranty:
-
1 Year
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Top Brand
-
Fork Length:
-
920mm
-
Fork Width:
-
100mm, 100-175mm
-
Overall Dimensions:
-
2245*1070*2070mm
-
Weight (KG):
-
2780 kg
-
Certification:
-
CE, ISO
-
Min.ground clearance:
-
110mm
-
Engine power:
-
34.5/2500
-
Free lift height(standard):
-
170mm
-
Height of Load-backrest:
-
995mm
-
Fuel tank capacity:
-
60L
Contact Way
Product Overview
forklift 1.5 ton diesel CPCD15 with parts
CPCD15: Load capacity 1500kg,hydraulic transmission,3m 2stage duplex mast,
China engine C490BPG,1070mm fork, Electronic gear transmission, key switch,
Pneumatic tyres,Safety seat,Free tool box and spare parts.
OPTION:
As a professional manufacturer of forklift, we also can offer you customized service,
the following items are optional:
Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m
side shifter, fork positioner,longer forks, fork extension
For the details of customized configurations and options, please contact with us.
Ergonomics Improved
Right located control lever effectively reduces driver’s arm tiredness;
Make the operator get wider and better visibility through creative and optimal design for the box iron, cylinders, chain of mast;
The operator’s legroom is twice to other series with optimized construction;
Conveniently behavior with electro-hydraulic direction changing lever and automobile type double joystick combined switch;
Small diameter steering wheel reduces driver’s left shoulder’s fatigue and makes driving comfortable;
Suspension seat with handrail and seat belt ensure the operator’s safety and comfort;
The dynamic braking system decreases the braking force sharply.
Reliability Improved
Automatic monitor control system could ensure the monitor working stably and safely;
The high strength special-shaped overhead guard is designed to ensure the safety;
Applying the park brake system safety protection device, avoid the hidden danger caused by faulty operation;
Safety wire harness, Reliability and good Maintainability;
More safety operation with the OPSS system;
Lower damping device inside the lifting system reduces mast shock and vibration, improving the whole truck’s safety and
reliability.
Applications: as lifting and transport machineries, G series 1-1.8T Diesel / Gasoline / LPG Counterbalanced Forklift Trucks are widely used for loading, unloading and transporting the packaged goods in factories, warehouses, stations, wharves, ports and so on. With other attachments of fork lift trucks, they can be used for the handling of the bulk goods and unpackaged goods.
As a professional manufacturer of forklift, we also can offer you customized service,
the following items are optional:
Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m
side shifter, fork positioner,longer forks, fork extension
For the details of customized configurations and options, please contact with us.
Lower pollution
High efficiency hydraulic system decreases the fuel consumption;
This lift truck is equipped with high performance engine to meet EU EC and USA EPA new regulations.
High efficiency hydraulic system decreases the fuel consumption;
This lift truck is equipped with high performance engine to meet EU EC and USA EPA new regulations.
Ergonomics Improved
Right located control lever effectively reduces driver’s arm tiredness;
Make the operator get wider and better visibility through creative and optimal design for the box iron, cylinders, chain of mast;
The operator’s legroom is twice to other series with optimized construction;
Conveniently behavior with electro-hydraulic direction changing lever and automobile type double joystick combined switch;
Small diameter steering wheel reduces driver’s left shoulder’s fatigue and makes driving comfortable;
Suspension seat with handrail and seat belt ensure the operator’s safety and comfort;
The dynamic braking system decreases the braking force sharply.
Reliability Improved
Automatic monitor control system could ensure the monitor working stably and safely;
The high strength special-shaped overhead guard is designed to ensure the safety;
Applying the park brake system safety protection device, avoid the hidden danger caused by faulty operation;
Safety wire harness, Reliability and good Maintainability;
More safety operation with the OPSS system;
Lower damping device inside the lifting system reduces mast shock and vibration, improving the whole truck’s safety and
reliability.
Applications: as lifting and transport machineries, G series 1-1.8T Diesel / Gasoline / LPG Counterbalanced Forklift Trucks are widely used for loading, unloading and transporting the packaged goods in factories, warehouses, stations, wharves, ports and so on. With other attachments of fork lift trucks, they can be used for the handling of the bulk goods and unpackaged goods.
Product Paramenters
|
Model
|
|
CPCD10
|
CPCD15
|
CPCD18
|
CPQ(Y)D10
|
CPQ(Y)D15
|
CPQ(Y)D18
|
|||||
|
Power type
|
|
Diesel
|
|
|
Gasoline/LPG
|
|
|
|||||
|
Load capacity
|
kg
|
1000
|
1500
|
1750
|
1000
|
1500
|
1750
|
|||||
|
Load center
|
mm
|
500
|
|
|
500
|
|
|
|||||
|
Max. lifting height
|
mm
|
3000
|
|
|
3000
|
|
|
|||||
|
Overall length(without forks)
|
mm
|
2166
|
2230
|
2273
|
2166
|
2230
|
2273
|
|||||
|
Overall width
|
mm
|
1075
|
|
1090
|
1075
|
|
1090
|
|||||
|
Overall height(overhead guard)
|
mm
|
2140
|
|
|
2140
|
|
|
|||||
|
Min. turning radius
|
mm
|
1870
|
1950
|
1980
|
1870
|
1950
|
1980
|
|||||
|
Max. travel speed(with/without load)
|
Km/h
|
17/18
|
|
|
|
|
|
|||||
|
Service weight
|
kg
|
2300
|
2760
|
2970
|
2300
|
2760
|
2970
|
|||||
Details Images
