Quick Details
-
Mold Height(mm):
-
150 - 350 mm
-
Ejector Number:
-
12
-
Ejector Stroke(mm):
-
50 mm
-
Ejector Force(kN):
-
20 kN
-
Theoretical Shot Volume(cm³):
-
183 cm³
-
Injection Rate (g/s):
-
112 g/s
-
Injection Weight (g):
-
139 g
-
Screw Speed (rpm):
-
1 - 200 rpm
-
Screw diameter (mm):
-
42 mm
-
Screw L/D Ratio:
-
20
-
Distance between Tie Bars:
-
395X255MM
-
Weight (KG):
-
3300 kg
-
Place of Origin:
-
Shandong, China
-
Open Stroke(mm):
-
200 mm
-
Model Number:
-
STIM550
-
Brand Name:
-
STEADY
-
Power (kW):
-
5.5 kW
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Application:
-
make plastic products
-
Product name:
-
TPR shoe sole injection molding machine
-
Keywords:
-
TPR shoe sole injection machine
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
-
Clamping Force (kN):
-
550 kN
-
Certification:
-
CE
-
Marketing Type:
-
New Product 2020
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
360mm
-
Distance between Tie Bars(Height)(mm):
-
360mm
-
Plasticizing Capacity(g/s):
-
21
-
Mold Height(mm):
-
150 - 350 mm
-
Ejector Number:
-
12
-
Ejector Stroke(mm):
-
50 mm
-
Ejector Force(kN):
-
20 kN
-
Theoretical Shot Volume(cm³):
-
183 cm³
-
Injection Rate (g/s):
-
112 g/s
-
Injection Weight (g):
-
139 g
-
Screw Speed (rpm):
-
1 - 200 rpm
-
Screw diameter (mm):
-
42 mm
-
Screw L/D Ratio:
-
20
-
Distance between Tie Bars:
-
395X255MM
-
Weight (KG):
-
3300 kg
-
Place of Origin:
-
Shandong, China
-
Open Stroke(mm):
-
200 mm
-
Model Number:
-
STIM550
-
Brand Name:
-
STEADY
-
Power (kW):
-
5.5 kW
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Application:
-
make plastic products
-
Product name:
-
TPR shoe sole injection molding machine
-
Keywords:
-
TPR shoe sole injection machine
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
-
Clamping Force (kN):
-
550 kN
-
Certification:
-
CE
-
Marketing Type:
-
New Product 2020
The TPR shoe sole injection molding machine is used to make plastic products. Can use material as below: 1. ABS/PA/PP/POM/PC/PVC/LCP/PBT+35% color plastic injection molding, etc. can also be used to color plastics manufacturer, color matching, shade guide, color palette.
1.Set all parameters on big size touch screen. Animation display all machine movement synchronously.
2. Screw and barrel made of high quality alloy steel, nitride surface treatment, heat, wear and corrosion resistance.
3.Horizontal clamping, horizontal injection, especially good at hign efficienty plastic products molding.
4.Fast speed, low pressure safety clamping, mold auto-open when abnormal happen, a unique safety design.
5.Automatic fault display and maintenance easy.
6.Electric control and hydraulic parts adopt famous brand, quiet, precise and durable.
7.Multi-zone temperature control, multi-stage injection pressure, injection speed, back pressure stepless adjustment, for precision plastic products molding.
Model:
For more details, please just feel free to contact me , we can give you a perfect proposal, most reasonable price, excellent quality machine(s) and best services.
Parts Detail Description:
1. Control Box
The control box electronics adopts Schneider or CHNT brand.
And our wire layout desing is very scientific.
The machine cotrol system adopts global top brand PORCHESON.
So the machine electronics is very reliable even in harsh working condition day and night continuous work .
2. Screw and Barrel Processing
Our Screw & Barrel Advantage is as below, ensures it's service life is 2 times more durable than other machines:
The material is: 38CrMOALA
Temper Degree:HB240°~280°
Nitriding Hardness:HV850°~1000°
Nitriding Deepness:0.45~0.7mm
Nitriding Brittleness:≤Grade Ⅱ
Surface Roughness:Ra0.4
Screw Straightness:0.015mm
Hard Chrome Plating after Nitriding:≥900HV
Chrome Thickness:0.05~0.10mm
Two-phase Alloys:HRC56°~65°(nickel-base alloy)
Alloy Deepness:1.5~2.0mm
3. Pump and Valves
4. LCD Real Time Display and Touch Screen Operation Panel
5. High Quality Molds Make First Class Products
For all the big machines, we load it into container and fixed and proper treatment.
For all the small machines, we use fumigation free wooden box with pallet base to pack and deliver.
7×24 hour on line technical service.
If necessiary, our engineer can go to provide service on spot.
