Quick Details
-
Fast Delivery:
-
12-15 working days finish
-
Low MOQ:
-
1 PC
-
Keypad Type:
-
Tactile or Non-tactile
-
Tactile Type:
-
Embossed button outside or metal/poly dome inside
-
Printing:
-
Silkscreen / Digital /UV Printing
-
HS Code:
-
8536500000 / 8538900000/8471607100
-
Price Term:
-
EXW / C&F/ FOB
-
Payment Term:
-
T/T, Paypal, Trade assurance
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Email:
-
Christina.liu(@)shmosun.cn
-
Certification:
-
ISO9001:2015 / ROHS
-
Fast Delivery:
-
12-15 working days finish
-
Low MOQ:
-
1 PC
-
Keypad Type:
-
Tactile or Non-tactile
-
Tactile Type:
-
Embossed button outside or metal/poly dome inside
-
Printing:
-
Silkscreen / Digital /UV Printing
-
HS Code:
-
8536500000 / 8538900000/8471607100
-
Price Term:
-
EXW / C&F/ FOB
-
Payment Term:
-
T/T, Paypal, Trade assurance
Product Detail As Below
Connector
We provide 3 type connector
1. Male
2. Female
3.ZIF
Tactile Feeling Button
How to have tactile feeling?
1. Button embossed outside
2. Metal dome inside (heavy feeling)
3. Poly dome inside (light feeling)
Tail
Customized Tail
1. Pls advise pitch
2. Pls advise what side is Pin 1 on
How to choose material?
PET
1. suit for bad outdoor environment, Anti-uv, corrosive
liquid,Oil pollution and other industrial grade supporting
products.
Polycarbonate
1.suit for Conventional indoor environment, no
requirement for corrosion products.
2. Button embossed:
PET only, thickness must less than 0.25mm
3. Instantaneous temperature: 180℃
4. Thickness: 0.125/0.15/0.188/0.2/0.28mm
2. Button Flat:
Polycarbonate or PET all available
3.Instantaneous temperature: 120℃
4. Thickness:0.175/0.25mm
Emboss Design Guide
Pad emboss type
The entire shape of the keypad is raised.
Rim emboss type
A rim around the perimeter of the keypad is raised
Dome emboss type
The entire keypad is raised to a spherical shape
Tolerances for Overlays and Circuits
Imaging: +/- .015" copy to edge. Die-cutting (Hole and perimeter size): +/- .010" hole to edge
