Quick Details
-
Filling Accuracy:
-
Other
-
Voltage:
-
220V/110V, AC220V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Willman
-
Dimension(L*W*H):
-
1900*800*1800mm
-
Weight:
-
860 KG
-
Product name:
-
Milk powder filling machine
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Filling head:
-
Single head
-
Safe package:
-
carton+foam
-
After Warranty Service:
-
No service
-
Nitrogen pressure:
-
0.1~0.8Mpa
-
Air supply:
-
0.6~0.8Mpa
-
Power:
-
3KW
-
Can diameter:
-
99-127mm
Quick Details
-
Machinery Capacity:
-
Other
-
Packaging Material:
-
Metal, Wood, Other
-
Filling Material:
-
Other
-
Filling Accuracy:
-
Other
-
Voltage:
-
220V/110V, AC220V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Willman
-
Dimension(L*W*H):
-
1900*800*1800mm
-
Weight:
-
860 KG
-
Product name:
-
Milk powder filling machine
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Filling head:
-
Single head
-
Safe package:
-
carton+foam
-
After Warranty Service:
-
No service
-
Nitrogen pressure:
-
0.1~0.8Mpa
-
Air supply:
-
0.6~0.8Mpa
-
Power:
-
3KW
-
Can diameter:
-
99-127mm
Product Description
milk powder canning machine
Introduction
|
Technical Parameter
|
|
|
|
Model
|
NFG-1
|
|
|
The number of capping head
|
1
|
|
|
Production capacity
|
When the vacuum is 90Kpa, the product capacity is 5-7 cans/min
|
|
|
Can diameter
|
99-127mm
|
|
|
Can height
|
100-200mm
|
|
|
Power
|
1.5KW
|
|
|
Weight
|
860kg
|
|
|
Dimension
|
1900*800*1800mm
|
|
|
Nitrogen pressure
|
0.1～0.8Mpa
|
|
|
Air supply
|
0.6～0.8Mpa
|
|
|
Power
|
3KW
|
|
|
Voltage
|
AC220V
|
|
Advantage
Well designed layout structure, combine vacuuming, nitrogen filling and seaming in one machine.
- Internal pressure can be set up by customer’s requirements
- Unique vacuuming chamber design and way of vacuuming can ensure the seaming quality.
- Use high-quality component – Siemens PLC, Omron proximity switch.
- Adjustable in Production speed with automatic alarming system, PLC can judge whether to stop the machine
- All gears are grinded and heat treated with a longer life of service. And the machine has lower noise running in high speed.
- Compact design in stainless steel, requires little space.
- Low Transportation Cost, entire machine can be placed in one sea freight container, the costs for shipment are accordingly low.
