Quick Details
-
Brand Name:
-
SZFAST
-
Model Number:
-
FAST-45-65LSS-M10
-
Application:
-
Level control,level measurement,water tank
-
Installation:
-
Vertical,M10
-
Detection:
-
Shortage or full water
-
Depth:
-
45~65 mm
-
Materials:
-
SUS304 Stem&Floater
-
Electrical Data:
-
10W,100V,0.5A
-
color:
-
metal black
-
Keyword:
-
ball float switch
-
Switching Form:
-
Normal Open N/O
-
Wire Length:
-
300mm(Standard)
Quick Details
-
Grade:
-
Industrial
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SZFAST
-
Model Number:
-
FAST-45-65LSS-M10
-
Application:
-
Level control,level measurement,water tank
-
Installation:
-
Vertical,M10
-
Detection:
-
Shortage or full water
-
Depth:
-
45~65 mm
-
Materials:
-
SUS304 Stem&Floater
-
Electrical Data:
-
10W,100V,0.5A
-
color:
-
metal black
-
Keyword:
-
ball float switch
-
Switching Form:
-
Normal Open N/O
-
Wire Length:
-
300mm(Standard)
Wholesale SUS304 M10 thread vertically stainless steel electronic ball float switch
1.Application:Water tank, water treatment,etc,used for detecting liquid level.
2.Installation:
Vertical Only and M10 thread
3.Detection:
Two Water Levels
4.Depth:
45~65 mm
5.Materials:
SUS304 Stem and 1×SUS304 Floater
6.Origin:China
7.MOQ:200pcs/carton
|
Model |
FAST-45-150LSS |
|
Application |
Water tank, water treatment,etc,used for detecting liquid level. |
|
Origin |
FAST SENSOR |
|
Installation |
Only Vertical |
|
Detected Depth |
L=45~150mm 150~500mm |
|
Product Material |
SS=SUS304 & SUS316 Stem &Ball SP= SUS304 & SUS316 Stem &PP Sealed Ball S= SUS304 & SUS316 Stem &PP Foam Ball |
|
Waterproof Ring |
in water, silica gel material ,clear color in oil, rubber material, black In ink & chemical liquid, EPDM material, black |
|
Electrical Data |
1=10W,100V,0.5A 2=70W,250V,0.5A 100W/400VAC/ 1A |
|
Switching Form |
A=Normal Open N/O |
|
Detected Level |
1=D1 Shortage alarm 2=D2 Full alarm |
|
Sensing Form |
V= Reversible Action No V= Irreversible Action |
|
Thread |
3/8", 1/8NPT,M10(42-150mm),M12(120-500mm) |
|
Wire Material |
W=Teflon#22 Blue(Standard) C3.8=φ3.8 Cable Black C4.5=φ4.5 Cable Black |
|
Wire Length |
300mm(Standard) 500 1000 Other |
|
Connector |
2Y=Made in China SM=Made in Korea JST=Made in Janpan Other |
|
Output Signal |
ON/OFF, 2 wires |
|
Temperature ℃ |
-40~+85 HT -40 ~ +140 |
|
Order Info. |
For example, FAST-45LSS-2A1V-M10-300W-2Y |
|
FAST-45mm depth,SUS304 stem and ball-70W,N/O, Shortage alarm from the bottom -M10-300mm,#22-Chinese connector |
