Industry 15000 Psi hydraulic plunger pump

Industry 15000 Psi hydraulic plunger pump

FOB Reference Price: Get Latest Price

≥1 Sets

US $2000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Warranty:: 12months, 12months

Brand Name:: JOYMANDE

Model Number:: JMEE

Place of Origin:: Tianjin, China

Horsepower:: High Pressure

Product name:: High pressure cleaner

Usage:: High pressure washer/Hydro testing

Transmission:: Gear/Speed reducer/Belt

Driven type:: Motor/Gasoline engine/Diesel engine

Pump material:: Stainless steel/304SS/316L/Duplex steel

Application2:: Pressure washer

Quick Details

Application:: Other, Automotive Industry, Biofuel Industry, Commercial Buildings, Developing World Water Solutions, District Energy, Drinking water treatment, Family Homes, Food and Beverage Industry, HVAC OEM, Industrial Boilers, Industrial Utilities, Irrigation and Agriculture, Machining, Marine, Metal and Equipment Manufacturers, Mining industry, Raw Water Intake, temperature control, Washing and Cleaning, Wastewater Transport and Flood Control, wastewater treatment, Water Distribution, Water Treatment Solutions

Pressure:: High Pressure

Voltage:: 380V, 380V/415V/420V/440V/450V/460V

Warranty:: 12months, 12months

Brand Name:: JOYMANDE

Model Number:: JMEE

Place of Origin:: Tianjin, China

Horsepower:: High Pressure

Product name:: High pressure cleaner

Usage:: High pressure washer/Hydro testing

Transmission:: Gear/Speed reducer/Belt

Driven type:: Motor/Gasoline engine/Diesel engine

Pump material:: Stainless steel/304SS/316L/Duplex steel

Application2:: Pressure washer

Product Description

Product Application

_{High pressure cleaner

High pressure cleaner machine is coming with motor and triplex plunger pump which is suitable as

pressure testing pump, cleaning pump,metering pump, process pump, dosing pump, hydro test pump, transfer pump, slurry pump, liquid carbon dioxide pump and so on

.}

_{Triplex plunger pump is widely used in the field of

pressure testing, pressure cleaning and washing,water blaster and water jetting, oil and gas, refinery, construction and building, car washing, and ship and so on.}

_{Assembling type: Horizontal type, Fixed type, and Trolley wheel type.

Drive type: Electric motor, Gasoline engine, Diesel engine.

Transmission type: Belt type, Gear box type, Speed reduction type.

Pump body material: Alloy steel, Martensitic stainless steel, Austenitic stainless steel, 316 & 316L stainless steel.}

Model	Pressure scope Mpa	Flow rate LPM	Power kW
JMEE20	4~45	21~0.7	1.1/2.2
JMEE35	2~50	65-1.5	1.1~7.5
JMEE40	2~60	153~2	2.2~11
JMEE60	2~100	330~3	2.2~45
JMEE75	4~140	230~2	8~55
JMEE75A	7~150	309~3	11~75
JMEE80	2~100	765~5.5	8~75
JMEE80A	10~200	600~6	30~120
JMEE90A	10~150	476~6	11~120
JMEE95A	10~150	472~4	11~120
JMEE100A	10~150	497~5	15~150
JMEE120	4~100	1020~12	30~120
JMEE120A	10~200	1196~6	30~300
JMEE130A	10~200	1106~14	55~300
JMEE140A	28~380	800~7	55~500
JMEE-160	4~150	1700~16	55~200
JMEE-150	6~150	1700~19	55~300
JMEE-170	6~100	1600~47	55~400
JMEE-200	6~50	2894~146	90~600
JMEE-270	10~50	5400~257	300~1110

Main Features

We offer several variations to accommodate any drive type. Whether you use the pressure washer intermittently around the house or run your system 40 hours per week, a quality pump is vital to a pressure washer.
Those who depend on pressure washers to get the job done rely heavily on JOY M&E pumps. We believe in producing only the highest quality and longest-lasting pump available. Partner with us and benefit from
Less repair cost
Less downtime
Greater profitability
Lower cost of ownership
JOY M&E pumps' product line includes the world's most dependable reciprocating triplex plunger pumps.

This design allows a cost-effective pump to achieve high-efficiency and low-pulsation. JMEE pumps field-proven dependability, efficiency, durability and versatility give users the best using experience.
With highly-efficient pumps and proven dependability, JOY M&E's products are utilized world-wide in thousands of applications.
A wide product range of plunger pumps are available: 3LPM to 1200LPM, 20bar to3000bar
Pumps are available in brass, nickel aluminum bronze, 316 stainless steel and duplex stainless steel.
Transmission type: Belt drive/ Gear box /Speed reduction type
Driven type: Electric motor/ Gasoline engine/ Diesel Engine.

Pump Detailed Images

High Pressure Washer/Hydro Test Pump

Transmission type: Belt

Brand: JOY M&E

Original: China

Pressure: 0-200Mpa (0-2000bar )

Motor power: 1.1kw-160kw

Application: Sea water desalination/ RO system pump /CO2 extraction / C02 filling / Pressure washing /

Truck washing / Ship cleaning /Sand blasting/Pressure testing / Slurry pump

High Pressure Washer/Hydro Test Pump

Transmission type : Speed reducer
Brand : JOY M&E
Original: China
Pressure: 0-200Mpa (0-2000bar )
Motor power: 1.1kw-160kw
Application: Sea water desalination/ RO system pump /CO2 extraction / C02 filling / Pressure washing /
Truck washing / Ship cleaning /Sand blasting/Pressure testing /Slurry pump

High Pressure Washer

Transmission type: Gearbox
Brand: JOY M&E
Original: China
Pressure: 0-280Mpa (0-2800bar )
Motor power: 1.1kw-300kw
Application: Pressure washing, Water blasting, Demolition, Concrete cleaning, Bridge cleaning, Paint washing, Rust cleaning, Building washing,Water injection, Condenser tube cleaning / Heat exchanger cleaning,shipyard cleaning.

High Pressure Water Blaster

Transmission type: Gear
Brand: JOY M&E
Original: China
Pressure: 0-280Mpa (0-2800bar )
Motor power: 1.1kw-300kw
Application: Pressure washing, Water blasting, Demolition, Concrete cleaning, Bridge cleaning, Paint washing, Rust cleaning, Building washing,Water injection, Condenser tube cleaning / Heat exchanger cleaning,shipyard cleaning.

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Design and customization support

* View our Factory.

After-Sales Service

* Timely tracking and service for each order

* Spare parts available with short time.

* Engineers available to service machinery overseas.

Packing & Delivery

Packaging
Size	123 (L) 800 (W) 900 (D)
Weight	1.2 T
Packaging Details	The normal package is wooden box(Size: LWH). Normally the machine is wrapped with PE film to prevent water and rusty during shipping. Outside is packed with wooden case. Or pack it according to customers special request.

Packaging
Size	123 (L) * 456 (W) * 789 (D)
Weight	1.2 T
Packaging Details	The normal package is wooden box(Size: LWH). Normally the machine is wrapped with PE film to prevent water and rusty during shipping. Outside is packed with wooden case. Or pack it according to customers special request.
