- Product Details
- {{item.text}}
Quick Details
-
D/C:
-
GC1513
-
Place of Origin:
-
Netherland
-
Application:
-
in household, industrial and special equipment
-
Cross Reference:
-
MKA50202
-
Brand:
-
Reed Switch
-
Features:
-
Micro Size and sensitive
-
Mounting Feature:
-
PCB
-
Size / Dimension:
-
5.6x50mm
-
Color:
-
Green
-
Material:
-
Glass Tube
-
Operating Temperature:
-
-40~260C
-
Mounting Type:
-
PCB
-
Switch Function:
-
Switching Signal
-
Current Rating (Amps):
-
0.5A
-
Voltage Rating - AC:
-
250
-
Voltage Rating - DC:
-
200
-
Packaging:
-
Glass Tube
-
Voltage Rating:
-
200Vdc/250Vac
-
Illumination Voltage (Nominal):
-
Not Applicable
-
Voltage - Switching AC:
-
250
-
Voltage - Switching DC:
-
200
-
Power - Rated:
-
0~200Vdc/250Vac
-
Voltage - Supply:
-
0~200Vdc/250Vac
-
Rated Voltage:
-
0~200Vdc/250Vac
-
Current - Switching:
-
0~5A
-
Size:
-
5x52mm
-
Contact Form:
-
Normally Open
-
Switched Power:
-
120V Max.
-
Switched Vdc/Vac:
-
1500 Max.
-
Switched Current:
-
3.0A/5.0A Max.
-
Breakdown Voltage:
-
3000V Min.
-
Contact Resistance:
-
80mΩ Max.
-
Temp. Range:
-
-40 ~ +125°C
-
Packing:
-
200pcs/box
Quick Details
-
Brand Name:
-
COMUS
-
Model Number:
-
GC1513
-
Type:
-
Switch Limit
-
D/C:
-
GC1513
-
Place of Origin:
-
Netherland
-
Application:
-
in household, industrial and special equipment
-
Cross Reference:
-
MKA50202
-
Brand:
-
Reed Switch
-
Features:
-
Micro Size and sensitive
-
Mounting Feature:
-
PCB
-
Size / Dimension:
-
5.6x50mm
-
Color:
-
Green
-
Material:
-
Glass Tube
-
Operating Temperature:
-
-40~260C
-
Mounting Type:
-
PCB
-
Switch Function:
-
Switching Signal
-
Current Rating (Amps):
-
0.5A
-
Voltage Rating - AC:
-
250
-
Voltage Rating - DC:
-
200
-
Packaging:
-
Glass Tube
-
Voltage Rating:
-
200Vdc/250Vac
-
Illumination Voltage (Nominal):
-
Not Applicable
-
Voltage - Switching AC:
-
250
-
Voltage - Switching DC:
-
200
-
Power - Rated:
-
0~200Vdc/250Vac
-
Voltage - Supply:
-
0~200Vdc/250Vac
-
Rated Voltage:
-
0~200Vdc/250Vac
-
Current - Switching:
-
0~5A
-
Size:
-
5x52mm
-
Contact Form:
-
Normally Open
-
Switched Power:
-
120V Max.
-
Switched Vdc/Vac:
-
1500 Max.
-
Switched Current:
-
3.0A/5.0A Max.
-
Breakdown Voltage:
-
3000V Min.
-
Contact Resistance:
-
80mΩ Max.
-
Temp. Range:
-
-40 ~ +125°C
-
Packing:
-
200pcs/box
