- Product Details
- {{item.text}}
Quick Details
-
Model:
-
UDXM-30
-
Capacity(KG/H):
-
600KG/H
-
Main speed:
-
960RPM
-
Spin slice size:
-
300mm
-
Screw diameter:
-
115mm
-
Screw Speed:
-
195RPM
-
Power:
-
1.5kw
-
Dimensions:
-
1560*480*1340mm
-
Weight:
-
320KG
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
UD
-
Use:
-
WHEAT CLEAN
-
Model:
-
UDXM-30
-
Capacity(KG/H):
-
600KG/H
-
Main speed:
-
960RPM
-
Spin slice size:
-
300mm
-
Screw diameter:
-
115mm
-
Screw Speed:
-
195RPM
-
Power:
-
1.5kw
-
Dimensions:
-
1560*480*1340mm
-
Weight:
-
320KG
Wheat Cleaning Machine Grain Wheat Cleaning Wheat Cleaning Machine Seed Cleaner
Product Description
The wheat falls evenly from the blanching into the winch, which is washed and suspended in water by the rotation of the winch's leaves and sent to the dryer. Gravels and other impurities sank into the gravels, sent in the opposite direction, fell into the end of the water tank sand hopper, sand blasting pipe to filter box. In addition, the dust discharged during wheat blanking will be discharged in time by the dust outlet square hole and carried away by the suction pipe, which is suitable for the cleaning section of the flour mill to separate the impurities such as stone and clay in wheat. By washing, it can not only remove pesticides, sand, mud, worm erosion grains, insect eggs and other harmful microorganisms in wheat, but also can play the role of watering wheat. The special grain properties and grinding properties of wheat can be changed according to the tempering process. This machine has the advantages of small power, high output, time saving and labor saving. It is the necessary equipment for grain cleaning and the ideal cleaning equipment for all flour manufacturers
Product Parameters
|
M odel |
UDXM-30 |
|
C apacity(KG/H) |
600KG/H |
|
M ain speed |
960RPM |
|
Spin slice size |
300mm |
|
Screw diameter |
115mm |
|
Screw Speed |
195RPM |
|
Power |
1.5kw |
|
Dimensions |
1560*480*1340mm |
|
Weight |
Weight |
If you need any othe model, Feel free ask me.
|
M odel |
UDXM-30 |
UDXM-40 |
UDXM-50 |
UDXM-60 |
UDXM-80 |
|
C apacity(KG/H) |
600KG/H |
1000 |
2000 |
3000 |
5000 |
|
M ain speed |
960RPM |
735RPM |
610RPM |
585RPM |
480RPM |
|
Spin slice size |
300mm |
400mm |
500mm |
600mm |
800mm |
|
Screw diameter |
115mm |
135mm |
135mm |
185mm |
185mm |
|
Screw Speed |
195RPM |
135RPM |
135RPM |
185RPM |
185RPM |
|
Power |
1.5kw |
3+1.1kw |
4+1.1kw |
5.5+1.5kw |
7.5+1.5KW |
|
Dimensions |
1560*480*1340mm |
1880*790*710mm |
2400*900*710mm |
2800*1100*1850mm |
3050*1200*2040mm |
|
Weight |
200kg |
500kg |
800kg |
1000kg |
1400kg |
