Function
1) Momentary/Jog:Press and hold=on, release=off 2)Toggle/Self-lock :Press 1 button=on,press the same button again=off
3)Latched/inter-lock:press 1 button =on,press other button=off
Jumper cap setting method
Momentary Pin1,2,3 and 4, No connection Toggle Pin 1 + 2 Latched Pin 3 + 4 1-4 Momentary 5-8 Toggle Pin 1 + 2,Pin 1 + 2
Clear Code and Learn Code
1) Learn Press the learning button 1 time,the learning LED turns on,then press the transmitter key to learn.the learning led
flashs and turns off. means learn sucessfully. 2) Clear Press the learning button for 5 seconds,the learning LED flashs and turns
off, that means the code has been cleared.
