Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
SEAFLO
-
Model Number:
-
SFGP1-032-003-01
-
Place of Origin:
-
Fujian, China
-
Outlet Size:
-
3/8" [10 mm] FNPT
-
Max Flow Rate:
-
3.2 GPM [12.0 LPM]
-
Head:
-
9.8' [3 m]
-
Self Priming:
-
3.2' [1 m] Suction
-
Pump Head Material:
-
Copper
-
Impeller Material:
-
Copper
-
Max Fluid Temp.:
-
140 °F [60 °C]
-
Duty Cycle:
-
Intermittent
-
Thermal Protection:
-
Yes
-
Fuel:
-
Battery, Solar Power or Transformer
-
Certification:
-
RoHS,ce
Quick Details
-
Application:
-
Automotive Industry, Family Homes, Industrial Utilities, Irrigation and Agriculture, Machining
-
Pressure:
-
Low Pressure
-
Voltage:
-
12 / 24 V DC
-
Warranty:
-
1 year
-
Brand Name:
-
SEAFLO
-
Model Number:
-
SFGP1-032-003-01
-
Place of Origin:
-
Fujian, China
-
Outlet Size:
-
3/8" [10 mm] FNPT
-
Max Flow Rate:
-
3.2 GPM [12.0 LPM]
-
Head:
-
9.8' [3 m]
-
Self Priming:
-
3.2' [1 m] Suction
-
Pump Head Material:
-
Copper
-
Impeller Material:
-
Copper
-
Max Fluid Temp.:
-
140 °F [60 °C]
-
Duty Cycle:
-
Intermittent
-
Thermal Protection:
-
Yes
-
Fuel:
-
Battery, Solar Power or Transformer
-
Certification:
-
RoHS,ce
| Features & Benefits |
|
1.Flow rate up to 3.2 GPM [12.0 LPM]
3.3/8" [9.52 mm] FNPT thread fittings 5.Quiet operation 7.Thermal protection |
2.Copper gear 4. Self priming 6.Stainless steel shaft 8.Designed for oil transfer |
| Product Name | SEAFLO 12V Diesel Fuel Transfer Pump 3.2GPM 12.0LPM for Oil Transfer |
| Pump Type | Gear Oil Transfer Pump |
| Voltage | 12 VDC, and 24V, 115V, 230V are available |
| Max Amp | 10.0 A |
| Fuse | 15.0 A |
| Max Flow Rate | 3.2 GPM [12.0 LPM] |
| Head | 9.8' [3 m] |
| Self Priming | 3.2' [1 m] suction |
| Inlet & Oulet Port | 3/8" [10 mm] FNPT, and contact us for more ports |
| Pump Head Material | Copper |
| Impeller Material | Copper |
| Duty Cycle | Intermittent |
| Thermal Protection | Yes |
| Max Fluid Temp | 140 °F [60 °C] |
| Lead | lead |
SEAFLO gear pumps are positive displacement pumps, capable of operation in either direction. They may be used to perform a variety of oil transfer applications (DO NOT USE FOR GASOLINE or other combustible fluids). We use robust motors, stainless steel shafts and rugged metal gears. Our tough design provides performance that you can rely on for years.
| Product Show |
| Dimensions |
Standard Pump Configurations
| Model | Voltage |
Open Flow GPM [LPM] |
Head Ft [m] |
Max Draw | Impeller | Inlet & Outlet Port |
| SFGP1-032-003-01 | 12 V | 3.2 [12.1] | 9.8' [3 m] | 10.0 A | Copper | 3/8" [10 mm] FNPT |
| SFGP2-032-003-01 | 24 V | 3.2 [12.1] | 9.8' [3 m] | 7.0 A | Copper | 3/8" [10 mm] FNPT |
OEM/ODM service: Pls contact us for OEM & ODM service.
Package Infomation
|
Unit Pump Weight | 5.30 lbs [2.40 kg] |
| Selling Unit Size (L x W x H) |
7.68" x 5.12" x 1.25" [19.5 x 13.0 x 10.8 cm] |
|
| Selling Unit Weight | 5.74 lbs [2.61 kg] | |
| Master Carton Qty | 8 pcs / carton | |
| Master Carton Size (L x W x H) |
21.65" x 8.39" x 9.65" [55.0 x 21.3 x 24.5 cm] |
|
| Master Carton Weight | 47.89 lbs[21.72 kg] |
