Quick Details
-
Warranty:
-
10YEARS
-
Model Number:
-
MSD400P
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1722x1134x30mm
-
Junction Box:
-
IP68,3*bypass diode
-
cable:
-
4.0mm²,(+)300mm/(-)300mm
-
Frame:
-
Anodized aluminum alloy
-
Tempered Glass:
-
3.2mm High Permeability Coated
-
Packaging type:
-
36 pcs/pallet
-
Open Circuit Voltage:
-
36.96V
-
Short Circuit Current:
-
13.82A
-
Voltage at Pmax:
-
30.65V
-
Current at Pmax:
-
13.06A
-
40HQ:
-
936pcs
-
Certificate:
-
CE,TUV,ICE,CQC
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Double-glass, All Black
-
Panel Efficiency:
-
22.5%
-
Warranty:
-
10YEARS
-
Model Number:
-
MSD400P
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1722x1134x30mm
-
Junction Box:
-
IP68,3*bypass diode
-
cable:
-
4.0mm²,(+)300mm/(-)300mm
-
Frame:
-
Anodized aluminum alloy
-
Tempered Glass:
-
3.2mm High Permeability Coated
-
Packaging type:
-
36 pcs/pallet
-
Open Circuit Voltage:
-
36.96V
-
Short Circuit Current:
-
13.82A
-
Voltage at Pmax:
-
30.65V
-
Current at Pmax:
-
13.06A
-
40HQ:
-
936pcs
-
Certificate:
-
CE,TUV,ICE,CQC
|
Electrical Parameters at STC
|
|
|
Module Type
|
MSD400P MSD410P MSD420P MSD430P
|
|
Rate Maximum Power（Pmax）
|
400 410 4520 430
|
|
Module Efficiency
|
20.5 21.0 22.0 22.5
|
|
Open Circuit Voltage（Voc）
|
36.96 37.23 37.58 37.75
|
|
Short Circuit Current（Isc）
|
13.82 14.00 14.41 14.74
|
|
Short Circuit Current（Isc）
|
30.65 30.95 31.32 31.59
|
|
Current at Pmax（Imp）
|
13.06 13.25 13.73 13.93
|
|
|
|
|
|
|
|
Mechanical Parameters
|
|
|
Solar Cell（Type/Size）
|
Mono(182mm)
|
|
Solar Cells Number
|
108pcs(6xl8)
|
|
Dimension
|
1722x1134x30mm
|
|
Weight
|
20.9kg/Pcs
|
|
Tempered Glass
|
3.2 Glass+EVA Film+Back
|
|
Junction Box
|
IP68/3*Bypass Diode
|
|
Cable
|
4.0mm²/300mm
|
|
Mechanical Load
|
Front 5400PA/back 2400PA
|
|
|
|
|
Packing
|
|
|
Number
|
36 pcs/pallet
|
|
40HQ Container
|
936 pcs
|
