Quick Details
-
Brand Name:
-
Sophpower
-
Model Number:
-
AVR-60K
-
Certificate:
-
CE
-
Display:
-
LCD
-
Efficiency:
-
98%
-
Warranty:
-
1years
-
Input Voltage:
-
380Vac 15%
-
Output voltage:
-
380V
-
Waveform Distortion:
-
1%
-
Type:
-
SCR
-
Capacity:
-
60KVA
Quick Details
-
Phase:
-
Three Phase
-
Current Type:
-
AC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sophpower
-
Model Number:
-
AVR-60K
-
Certificate:
-
CE
-
Display:
-
LCD
-
Efficiency:
-
98%
-
Warranty:
-
1years
-
Input Voltage:
-
380Vac 15%
-
Output voltage:
-
380V
-
Waveform Distortion:
-
1%
-
Type:
-
SCR
-
Capacity:
-
60KVA
2) Anti-interference, strong purifying ability, no wave distortion.
3) Response time ≤ 40ms, compatible with all loads.
4) Three phases are regulated independently to ensure the balance of output voltage.
5) Modular design, assembly, debugging, replacement and maintenance are simple and quick.
2) Industrial Power Supply
3) IT / SMT Production Line
4) Medical Industry
5) Transportation
|
Model
|
AVR-40K
|
AVR-50K
|
AVR-60K
|
|||
|
Capacity(kVA)
|
40kVA
|
50kVA
|
60kVA
|
|||
|
Control circuit
|
SCR contactless (CPU digital circuit)
|
|
|
|||
|
Input Specifications
|
|
|
|
|||
|
Input Voltage
|
3 ϕ 3W+N; 380VAC
|
|
|
|||
|
Voltage Range
|
380VAC ± 15%
|
|
|
|||
|
Frequency
|
50/60 Hz
|
|
|
|||
|
Output Specifications
|
|
|
|
|||
|
Output Voltage
|
3 ϕ 3W+N; 380VAC
|
|
|
|||
|
Accuracy
|
±1% (3%，Opt. 5%)
|
|
|
|||
|
Power Factor
|
PF≥0.8
|
|
|
|||
|
Efficiency
|
≥98%
|
|
|
|||
|
Response Time
|
≤40ms
|
|
|
|||
|
Delay Output
|
≤5s（Opt.）
|
|
|
|||
|
THD
|
≤1℅
|
|
|
|||
|
Over-load Capacity
|
150%-90s, 200%-20s
|
|
|
|||
|
Protection
|
|
|
|
|||
|
Over Voltage
|
Output>110% rated voltage, cut off input power in 3~5s
|
|
|
|||
|
Under Voltage
|
Output<115% rated voltage, cut off input power in 3~5s
|
|
|
|||
|
Over Load
|
Cut off input power within 5s
|
|
|
|||
|
Phase Dislocation
|
Alarm and cut off input power
|
|
|
|||
|
Phase Lack
|
Alarm and cut off input power
|
|
|
|||
|
Short Circuit
|
Cut off input power
|
|
|
|||
|
By-pass
|
Manual or Automatic bypass switch
|
|
|
|||
|
Generally
|
|
|
|
|||
|
LCD Display
|
Input Voltage, Output Voltage, Output Current, Working Status
|
|
|
|||
|
Cooling
|
Air cooling
|
|
|
|||
|
Insulation Resistance
|
≥2MΩ
|
|
|
|||
|
Insulation Grade
|
2000VAC
|
|
|
|||
|
Noise
|
＜65dB
|
|
|
|||
|
Temperature
|
0℃-45℃
|
|
|
|||
|
Relative Humidity
|
20%-90% (non-condensation)
|
|
|
|||
|
Size (W*H*D)mm
|
380*852*792
|
|
|
|||
|
Weight (Kg)
|
100
|
130
|
150
|
|||
|
Model
|
Specification
|
|
Voltage regulator ( three phase input, three phase output. 20kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 30kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 50kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 60kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 80kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 100kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 120kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 150kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 200kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 250kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 300kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 400kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 500kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 600kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 800kVA)
|
|
|
Voltage regulator ( three phase input, three phase output. 1000kVA)
|
