Quick Details
-
Filling Accuracy:
-
≤±1%
-
Driven Type:
-
Electric and pneumatic
-
Voltage:
-
220V /110V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GZHMD
-
Dimension(L*W*H):
-
L1110*W650*H420mm
-
Weight:
-
50.5 KG
-
Machinery Test Report:
-
Not Available
-
Machine model:
-
LFM-04
-
Power supply:
-
110/220V 50-60HZ
-
Maximum flow velocity:
-
5500ml/min (Each nozzle and base on water)
-
Working speed:
-
20-30 bottles/min (based on 50-1000ml filing volume)
-
Air pressure:
-
0.3-0.4MPa
-
Filling accuracy:
-
≤±1% (For water)
-
Diameter of Flling Nozzle:
-
6/8mm
-
Delay Range:
-
0.01-999.9s
-
Count Range:
-
1-99999 Times
-
Filling Volume:
-
3-1000ml(220V)3- 500ml(110V)
Quick Details
-
Machinery Capacity:
-
About 1500-3000 bttles/hour
-
Packaging Material:
-
Wood
-
Filling Material:
-
Milk, Water, Oil, Juice, Liquid
-
Filling Accuracy:
-
≤±1%
-
Driven Type:
-
Electric and pneumatic
-
Voltage:
-
220V /110V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GZHMD
-
Dimension(L*W*H):
-
L1110*W650*H420mm
-
Weight:
-
50.5 KG
-
Machinery Test Report:
-
Not Available
-
Machine model:
-
LFM-04
-
Power supply:
-
110/220V 50-60HZ
-
Maximum flow velocity:
-
5500ml/min (Each nozzle and base on water)
-
Working speed:
-
20-30 bottles/min (based on 50-1000ml filing volume)
-
Air pressure:
-
0.3-0.4MPa
-
Filling accuracy:
-
≤±1% (For water)
-
Diameter of Flling Nozzle:
-
6/8mm
-
Delay Range:
-
0.01-999.9s
-
Count Range:
-
1-99999 Times
-
Filling Volume:
-
3-1000ml(220V)3- 500ml(110V)
Machine parameter
|
Machine model
|
LFM-04
|
|
|
Power supply
|
110/220V 50-60HZ
|
|
|
Maximum flow velocity
|
5500ml/min
(Each nozzle and base on water) |
|
|
Working speed
|
20-30 bottles/min
(based on 50-1000ml filing volume) |
|
|
Air pressure
|
0.3-0.4MPa
|
|
|
Filling accuracy
|
≤±1% (For water)
|
|
|
Diameter of Flling Nozzle
|
6/8mm
|
|
|
Delay Range
|
0.01-999.9s
|
|
|
Count Range
|
1-99999 Times
|
|
|
Filling Volume
|
3-1000ml(220V)3- 500ml(110V)
|
|
|
Size of air compressor connector
|
OD8mm
|
|
|
Bottle height
|
＜220mm(Can be customized,max height 300mm)
|
|
|
Package Size
|
About 1110*650*420mm
|
|
|
Gross weight
|
About 50.5kg
|
|
