Quick Details
-
Board Size:
-
72.5x72.5mm
-
Model Number:
-
XP-5886
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Copper Thickness:
-
Hoz-5oz
-
Min. Hole Size:
-
0.25mm
-
Min. Line Width:
-
0.1mm
-
Min. Line Spacing:
-
0.1mm
-
Surface Finishing:
-
Immersion gold
-
Item::
-
Multilayers PCB
-
Materials:
-
FR4
-
Layers:
-
1-30L
-
Surface Finish:
-
HASL; Lead-free HASL; OSP; immersion silver; immersioin gold
-
Solder Mask Color:
-
Green Oil;Red;Yellow.Optional
-
Files Needed:
-
GERBER File
-
Sample Orders:
-
Acceptable
-
Payment:
-
L/C;T/T;Western Union;Paypal;ESCROW,etc.
-
Port:
-
SZ/HK
Quick Details
-
Number of Layers:
-
1-30Layers
-
Base Material:
-
FR-4
-
Board Thickness:
-
1.0mm
-
Board Size:
-
72.5x72.5mm
-
Model Number:
-
XP-5886
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Copper Thickness:
-
Hoz-5oz
-
Min. Hole Size:
-
0.25mm
-
Min. Line Width:
-
0.1mm
-
Min. Line Spacing:
-
0.1mm
-
Surface Finishing:
-
Immersion gold
-
Item::
-
Multilayers PCB
-
Materials:
-
FR4
-
Layers:
-
1-30L
-
Surface Finish:
-
HASL; Lead-free HASL; OSP; immersion silver; immersioin gold
-
Solder Mask Color:
-
Green Oil;Red;Yellow.Optional
-
Files Needed:
-
GERBER File
-
Sample Orders:
-
Acceptable
-
Payment:
-
L/C;T/T;Western Union;Paypal;ESCROW,etc.
-
Port:
-
SZ/HK
Shenzhen multilayer coffee machine circuit board manufacture and coffee maker control board pcb Precision rigid flex pcb
Mlultilayer pcb with layer layer PCB include HDI board ( 2 step HDI board)
Detailed Product Description
1) Material: FR4;
2) Certificate: UL, ISO, TS16949;
3) T/T,Western Union, Paypal
4)OEM service;
5)High quality.
2) Certificate: UL, ISO, TS16949;
3) T/T,Western Union, Paypal
4)OEM service;
5)High quality.
Mutilayers PCB HDI Circuit Board
1. ONE-STOP-SERVICE
2. OEM service
3. Gerber file needed
4. PCB clone with sample
5. Quality guarantee and professional after-sell service
Reference - Our Production Capability for Multilayer PCB/Rigid borad
|
Item
|
Multilayers PCB High Density Circuit Board
|
|
Layer count
|
1-30 layers
|
|
Material
|
FR4(High TG, Halogen Free, high frequency), CEM1, CEM3,BT,Al base mateiral,and so on.
Supplier: SY,KB,ITEQ,Isola,Nelco,Rogers,Grance,Mitsui
|
|
Maxpanel size
|
32±20(800mm±508mm)
|
|
Min width/space(min)
|
4mil/4mil
|
|
Max copper weight
|
140um(4oz) for inner layer
175um(5oz) for outer layer
|
|
Min machine drill size
|
0.2mm(8mil)
|
|
Via hole tpye
|
Blind/Burried/plugged
|
|
Thickness of finished board
|
0.20-6.0mm
|
|
Tolerance
|
Registration of innerlayer to of innerlayer:±3mil
Accuracy of hole position:±2mil
Tolerance of dilled slot:±3mil
Tolerance of PTH diameter:±3mil
Tolerance of NPTH diameter:±2mil
PTH hole copper thichness: 0.4-2mil
Image to image tolerance:±3mil
Tolerance of etching:±1mil
Solder mask registration tolerance: ±2mil
Finished board : Thickness<=1.0mm: +/-0.1mm
Thickness>0.1mm:+/-10%
Outline router: +/-0.1mm
Outline Score: +/-0.2mm
|
|
Color of solder mask
|
Green, Black, Blue,Red, White and so on
|
|
Surface freatment
|
HASL,HASL Lead Free,OSP ,Immersion Gold, Immersion Ti, Immersion Sliver, Flash gold, Selective Gold plating(gold thicness up to 120u),Gold figers ,Carbon print, Peelabe Mask
|
|
Hardness of solder solder
|
>=6H
|
|
Outline finished
|
CNC, V-CUT, Punching
|
|
Peel strength of line
|
≥61B/in
|
|
Warp and twist
|
≤0.7%
|
