Quick Details
-
Insulation Material:
-
Rubber
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
HGS 3135
-
Product name:
-
Copper Core PVC Insulation Wire
-
Color:
-
Optional
-
Conductor:
-
Stranded tinned Copper
-
Insulation:
-
Silicone Rubber
-
Rated Voltage:
-
600V
-
Material:
-
Tinned copper
-
Rated Temperature:
-
-60~ 200
-
Feature:
-
High Resistance
-
Usage:
-
Heating Product
-
Package:
-
305m/roll
Quick Details
-
Application:
-
Heating
-
Conductor Material:
-
tinned copper
-
Conductor Type:
-
Stranded
-
Insulation Material:
-
Rubber
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
HGS 3135
-
Product name:
-
Copper Core PVC Insulation Wire
-
Color:
-
Optional
-
Conductor:
-
Stranded tinned Copper
-
Insulation:
-
Silicone Rubber
-
Rated Voltage:
-
600V
-
Material:
-
Tinned copper
-
Rated Temperature:
-
-60~ 200
-
Feature:
-
High Resistance
-
Usage:
-
Heating Product
-
Package:
-
305m/roll
3135 High Flame Retardant 12 14 16 18 20 22 AWG High Voltage Silicone Flexible Electrical Wire
| HGS 3135 | ||||||
| Conductor | Insulator | Maximum Resistance | Packing | |||
| AWG | No/mm | Dia(mm) | Average Thickness(mm) | O.D(mm) | At20℃ Ω/KM | Mt/coils |
| 26 | 7/0.16 | 0.48 | 0.76 | 2.00 | 139 | 305 |
| 24 | 11/0.16 | 0.61 | 0.76 | 2.17 | 88.9 | 305 |
| 22 | 12/0.178 | 0.71 | 0.76 | 2.30 | 57.5 | 305 |
| 20 | 20/0.178 | 0.91 | 0.76 | 2.50 | 35.2 | 305 |
| 18 | 30/0.178 | 1.12 | 0.76 | 2.70 | 23.3 | 305 |
| 16 | 50/0.178 | 1.45 | 0.76 | 3.05 | 15.1 | 305 |
| 14 | 41/0.25 | 1.84 | 0.81 | 3.50 | 9.2 | 305 |
| 12 | 65/0.25 | 2.32 | 0.81 | 3.95 | 5.4 | 200 |
| 24 | 7/0.20 | 0.61 | 0.76 | 2.17 | 88.9 | 305 |
| 22 | 7/0.25 | 0.76 | 0.76 | 2.30 | 57.5 | 305 |
| 20 | 7/0.30 | 0.91 | 0.76 | 2.50 | 35.2 | 305 |
| 18 | 7/0.39 | 1.19 | 0.76 | 2.75 | 23.3 | 305 |
| 16 | 7/0.50 | 1.52 | 0.76 | 3.10 | 15.1 | 305 |
