- Product Details
- {{item.text}}
Quick Details
-
Power:
-
7.5KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Rhinoceros
-
Maximum Digging Height:
-
2646mm
-
Maximum Digging Depth:
-
1568mm
-
Machine Weight:
-
1000 kg
-
Max Digging Radius:
-
3136mm
-
Rated Speed:
-
1.5km/h
-
Marketing Type:
-
New Product
-
Engine type:
-
Single cylinder diesel oil engine
-
Rated power:
-
7KW / 10.2KW
-
Main pump:
-
CBK-F6.8
-
Swing motor:
-
SJ-TECH
-
Traveling motor:
-
EATON
-
Rubber track width:
-
180mm
-
Max. Dumping height:
-
1655mm
-
Loading:
-
12 units in 40FT
-
Delivery time:
-
Within 7 days
Quick Details
-
Operating Weight:
-
1ton
-
Bucket capacity:
-
0.025cbm
-
Engine Brand:
-
Changchai
-
Power:
-
7.5KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Rhinoceros
-
Maximum Digging Height:
-
2646mm
-
Maximum Digging Depth:
-
1568mm
-
Machine Weight:
-
1000 kg
-
Max Digging Radius:
-
3136mm
-
Rated Speed:
-
1.5km/h
-
Marketing Type:
-
New Product
-
Engine type:
-
Single cylinder diesel oil engine
-
Rated power:
-
7KW / 10.2KW
-
Main pump:
-
CBK-F6.8
-
Swing motor:
-
SJ-TECH
-
Traveling motor:
-
EATON
-
Rubber track width:
-
180mm
-
Max. Dumping height:
-
1655mm
-
Loading:
-
12 units in 40FT
-
Delivery time:
-
Within 7 days
XN10-8 Rhinoceros 1 ton Newest Model Mini Digger mini walking excavator
XN10-8 crawler excavator is a collection of beautiful design, high configuration, good performance, low fuel consumption with wide operating ranges. It is suitable for loosing soil of vegetable greenhouse, municipal departments’ landscape engineering, digging holes for tree planting in orchard, crushing concrete surface and sand-gravel mixing material, small space working sites etc. Adopting quick hitch that make you change working attachment easy and fast, and also can reduce maintenance and operating cost.
Product Paramenters
|
SPECIFICATION
|
|
|
|
Model
|
XN10-8
|
|
|
Brand
|
RHINOCEROS
|
|
|
Machine Weight
|
1000kg
|
|
|
Bucket capacity
|
0.025cbm
|
|
|
Bucket width
|
380mm
|
|
|
Engine
|
CHANGCHAI
|
|
|
Rated power
|
7.5 kw/3000r/min
|
|
|
Swing speed
|
10.5rpm
|
|
|
Max. Grade ability
|
30°
|
|
|
Pump type
|
Gear pump
|
|
|
Pressure
|
16MPa
|
|
|
Flow rate
|
16.6L/min
|
|
|
MAIN DEMENSIONS
|
|
|
|
Overall dimension( LxWxH)
|
2850x954/800x2211 mm
|
|
|
Wheelbase
|
914 mm
|
|
|
Total length of track
|
1234mm
|
|
|
Upper chassis ground clearance
|
453mm
|
|
|
Counterweight turning radius
|
660 mm
|
|
|
Track width
|
180 mm
|
|
|
Track height
|
320 mm
|
|
|
Height of seat to ground
|
1525mm
|
|
|
Boom swing - left
|
363mm
|
|
|
Boom swing - right
|
325mm
|
|
|
OPERATING RANGE
|
|
|
|
Max. Digging depth
|
1568 mm
|
|
|
Max. Vertical digging depth
|
1377mm
|
|
|
Max. Digging height
|
2646 mm
|
|
|
Max. Dumping height
|
1876mm
|
|
|
Max. Digging radius on ground
|
3039mm
|
|
|
Min. Rotation radius
|
1510mm
|
|
|
Max. Lifting height of dozer blade
|
141 mm
|
|
|
Max. Digging depth of bulldozer blade
|
200mm
|
|
Details Images
The upper hood can be fully opened to facilitate daily inspection and mainenance.
Comfortable seat designed according to ergonomics, equipped with slides and armrests
Stronger ROPS
Anti-roll steel frame can
ensures operator safety, and the frame can folded when the excavator is transported.
Solid cast iron counterweight,
greatly improves the stability of the excavator.
The use of swing boom components greatly expands the working range of the excavator. Some narrow spaces that cannot be directly accessed can be easily accessed with this component.
Telescopic chassis
Generally, the chassis is in a normal state, when a more stable grip effect is required, the chassis can be
extended
to both sides to enhance the stability of the chassis. But when you encounter a narrow passage, you can retract the chassis to the inside and pass the narrow passage smoothly
