- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
ENWEI
-
Weight:
-
800kg
-
Dimension(L*W*H):
-
100*50*80 cm
-
Keywords:
-
Vertical hydraulic baler
-
Packed weight (kg):
-
150-200
-
Packed size (cm):
-
160*90*280
-
Pressure:
-
30 Ton
-
Certification:
-
CE
Quick Details
-
Voltage:
-
220V/380V
-
Power:
-
11KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ENWEI
-
Weight:
-
800kg
-
Dimension(L*W*H):
-
100*50*80 cm
-
Keywords:
-
Vertical hydraulic baler
-
Packed weight (kg):
-
150-200
-
Packed size (cm):
-
160*90*280
-
Pressure:
-
30 Ton
-
Certification:
-
CE
Products Description
Hydraulic baler is suitable for straw, forage, waste paper packing, cotton packing, garment packing, straw packing, plastic packing, wool packing, recyclable garbage packing, cotton, wool, waste paper box, waste paperboard , yarn, tobacco, plastic, cloth, woven bags, knitted cashmere, hemp, sacks, tops, hair balls, silk, silk, hops, waste plastic bags, and other soft materials such as light foam, loose materials, etc. Compact, tidy and aesthetically pleasing, significantly reducing transportation costs
Application:
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Product Paramenters
|
Parameters of Hydraulic Baler Technical
|
|
|
|
|
|
|
|
|
||||||||
|
Model |
Pressure (T) |
Cylinder stroke (cm)
|
Cylinder diameter
(mm) |
Power (kw) |
Packed size (cm)
L*W*H |
Packed weight (kg) |
Size (cm) L*W*H |
Weight (kg) |
||||||||
|
10T single cylinder
|
10 |
100 |
115 |
7.5 (Three-phase asynchronous motor)
|
80*40*70 |
50-70 |
150*70*270 |
400 |
||||||||
|
20T single cylinder
|
20 |
100 |
140 |
7.5 (Three-phase asynchronous motor)
|
80*40*70 |
100-120 |
150*70*270 |
550 |
||||||||
|
30T single cylinder
|
30 |
100 |
160 |
11 (Three-phase asynchronous motor)
|
100*50*80 |
100-120 |
180*80*280 |
700 |
||||||||
|
30T double cylinder
|
30 |
100 |
118 |
11 (Three-phase asynchronous motor)
|
100*50*80 |
150-200 |
160*90*280 |
800 |
||||||||
|
40T double cylinder
|
40 |
100 |
140 |
11 (Three-phase asynchronous motor)
|
110*60*80 |
200-300 |
170*100*280 |
900 |
||||||||
|
60T double cylinder (Automatic push bag)
|
60 |
100 |
160-2 |
15 (Three-phase asynchronous motor)
|
120*80*100 |
200-300 |
160*120*280 |
1300 |
||||||||
|
80T double cylinder (Automatic push bag)
|
80 |
110 |
180-2 |
15/18 (Three-phase asynchronous motor)
|
120*80*100 |
300-350 |
180*130*280 |
1800 |
||||||||
|
100T double cylinder (Automatic push bag)
|
100 |
120 |
190-2 |
22 (Three-phase asynchronous
|
130*100*100 |
300-400 |
180*30*290 |
2300 |
||||||||
The fuel tank cylinder is folded at one time with thick steel plate material, the sealing performance is better without oil leakage, and the main oil pressure rod is used to assist the steady rise and fall.
Full copper wire motor, good heat dissipation, strong power and stable transmission.
It adopts thickened steel plate material, with large bearing pressure, firmness and no deformation, and more compact pressing package.
The imported valve start switch is adopted. When lowering, the press rod pushes the press plate material to rise and the press rod press plate to rise. The operation is convenient.
There is no noise when the machine rises. Turn the switch to turn on the mute mode.
The door lock is thickened and reinforced, the door can be opened and closed quickly and tightly.
Company Certifications
Factory Show
Product packaging
FAQ
1. who are we? We are based in Shandong, China, start from 2014, sell to South America (10.00%), Eastern Europe (10.00%), Southeast Asia (10.00%), Africa (10.00%), Mid East (10.00%), Eastern Asia (10.00%), Western Europe (10.00%), North America (5.00%), Central America (5.00%), Northern Europe (5.00%), Southern Europe (5.00%), South Asia (5.00%), Domestic Market (5.00%).There are total about 501-1000 people in our office.
2. how can we guarantee quality? Always a pre-production sample before mass production; Always final Inspection before shipment; To our customers, the company promises, all the products of the company, and there are non- human factors quality problems during the warranty period, unconditional return or refund.
3.what can you buy from us? Mining Machinery, Construction Machinery, Drill Machine, Road machinery, Pump.
4. why should you buy from us not from other suppliers? Research and development, sales, production in one, there is a sound technology, sales, service departments. Have perfect after-sales service, so that customers more peace of mind, more assured.
3.what can you buy from us? Mining Machinery, Construction Machinery, Drill Machine, Road machinery, Pump.
4. why should you buy from us not from other suppliers? Research and development, sales, production in one, there is a sound technology, sales, service departments. Have perfect after-sales service, so that customers more peace of mind, more assured.
