- Product Details
- {{item.text}}
Quick Details
-
Tolerance:
-
±1%
-
Invoicing:
-
by actual weight
-
Place of Origin:
-
China
-
Brand Name:
-
JIAHAO STEEL
-
Model Number:
-
Angle Steel, Equal
-
Size:
-
45X32X270mm,Custom Size
-
Thickness:
-
3mm,Custom Size
-
Application Range:
-
Appliance Car Building etc.
-
Certificate:
-
ISO9001 ce as customer's needs
-
Length:
-
6m or as customer required
-
Quality:
-
High Quality Inspection
-
Medium Angle:
-
between 12.5cm and 5cm
-
Large Angle steel:
-
the side length is above 12.5cm
-
Small Angle steel:
-
side length below 5cm
Quick Details
-
Standard:
-
AiSi ASTM bs DIN GB JIS EN
-
Grade:
-
Q195-Q420 Series SS400-SS540 Series
-
Type:
-
Equal
-
Tolerance:
-
±1%
-
Invoicing:
-
by actual weight
-
Place of Origin:
-
China
-
Brand Name:
-
JIAHAO STEEL
-
Model Number:
-
Angle Steel, Equal
-
Size:
-
45X32X270mm,Custom Size
-
Thickness:
-
3mm,Custom Size
-
Application Range:
-
Appliance Car Building etc.
-
Certificate:
-
ISO9001 ce as customer's needs
-
Length:
-
6m or as customer required
-
Quality:
-
High Quality Inspection
-
Medium Angle:
-
between 12.5cm and 5cm
-
Large Angle steel:
-
the side length is above 12.5cm
-
Small Angle steel:
-
side length below 5cm
Customization can be made according to your needs!!!
| Size | Theoretical weight | Size | Theoretical weight | Size | Theoretical weight |
| (mm) | (kg/m) | (mm) | (kg/m) | (mm) | (kg/m) |
| 25*3 | 1.124 | 75*7 | 7.976 | 110*14 | 22.809 |
| 25*4 | 1.459 | 75*8 | 9.03 | 125*8 | 15.504 |
| 30*3 | 1.373 | 75*10 | 11.089 | 125*10 | 19.133 |
| 30*4 | 1.786 | 80*6 | 7.376 | 125*12 | 22.696 |
| 40*3 | 1.852 | 80*7 | 8.525 | 125*14 | 26.193 |
| 40*4 | 2.422 | 80*8 | 9.658 | 140*10 | 21.488 |
| 40*5 | 2.976 | 80*10 | 11.874 | 140*12 | 25.522 |
| 50*4 | 3.059 | 90*6 | 8.35 | 140*14 | 29.49 |
| 50*5 | 3.77 | 90*7 | 9.658 | 140*16 | 35.393 |
| 50*6 | 4.465 | 90*8 | 10.946 | 160*10 | 24.729 |
| 60*5 | 4.52 | 90*10 | 13.476 | 160*12 | 29.391 |
| 60*6 | 5.42 | 90*12 | 15.94 | 160*14 | 33.987 |
| 63*5 | 4.822 | 100*6 | 9.366 | 160*16 | 38.518 |
| 63*6 | 5.721 | 100*7 | 10.83 | 180*12 | 33.159 |
| 63*8 | 7.469 | 100*8 | 12.276 | 180*14 | 38.518 |
| 63*10 | 9.151 | 100*10 | 15.12 | 180*16 | 43.542 |
| 70*5 | 5.397 | 100*12 | 20.611 | 180*18 | 48.634 |
| 70*6 | 6.406 | 100*16 | 23.257 | 200*14 | 42.894 |
| 70*7 | 7.398 | 110*7 | 11.928 | 200*16 | 48.68 |
| 70*8 | 8.373 | 110*8 | 13.532 | 200*18 | 54.401 |
| 75*5 | 5.818 | 110*10 | 16.69 | 200*20 | 60.056 |
No cutting corners or cutting materials, the product's cut surface is flat and free of burrs.
The surface of angle steel is usually treated with hot-dip galvanizing to improve its rust resistance and prolong its service life.
Angle steel is easy to process and can be processed by cutting, bending, drilling, and other methods.
