Quick Details
-
Color:
-
Gray/blue/white or Customized
-
Conductor:
-
CCS/CCAM/BC 0.6mm or customized
-
Shield:
-
Al Foil
-
Jacket:
-
PVC
-
Insulation:
-
PE
-
Length:
-
100m/200m/300m/customized
-
Packing:
-
Coil/Plastic Reel/Wooden reel/Carton
-
Name:
-
Telephone cable multicore
-
Certification:
-
CE/RoHS/ISO9001/CPR/Reach
Quick Details
-
Brand Name:
-
Aite or OEM
-
Model Number:
-
ATLCOO2
-
Place of Origin:
-
Zhejiang, China
-
Color:
-
Gray/blue/white or Customized
-
Conductor:
-
CCS/CCAM/BC 0.6mm or customized
-
Shield:
-
Al Foil
-
Jacket:
-
PVC
-
Insulation:
-
PE
-
Length:
-
100m/200m/300m/customized
-
Packing:
-
Coil/Plastic Reel/Wooden reel/Carton
-
Name:
-
Telephone cable multicore
-
Certification:
-
CE/RoHS/ISO9001/CPR/Reach
Production Video
|
Basic Construction
|
|
|
|
|
|
|
|
|||||||
|
|
|
2pairs
|
|
4pairs
|
6pairs
|
8pairs
|
10pairs
|
|||||||
|
Conductor
|
Material
|
CCAM
|
|
|
|
|
|
|||||||
|
|
Nom.Dia
|
0.60MM
|
|
|
|
|
|
|||||||
|
Dielectric
|
Material
|
PE
|
|
|
|
|
|
|||||||
|
|
Nom.Dia
|
1.00MM
|
|
|
|
|
|
|||||||
|
Shield
|
Material
|
AL Foil
|
|
|
|
|
|
|||||||
|
|
Coverage
|
100%
|
|
|
|
|
|
|||||||
|
Drain wire
|
Material
|
CCA
|
|
|
|
|
|
|||||||
|
|
Nom.Dia
|
0.60MM
|
|
|
|
|
|
|||||||
|
Jacket
|
Material
|
Grey PVC
|
|
|
|
|
|
|||||||
|
|
Nom.Dia
|
0.70MM
|
|
|
|
|
|
|||||||
|
Conductor Resistance Ω/km
|
|
≤186
|
|
|
|||
|
Insulation Resistance
|
|
≥5000MΩ.KM
|
|
|
|||
|
AC Voltage Test(1500V,1 min ,1M)
|
|
No Breakdown
|
|
|
|||
|
DC Voltage Test(2250V,1 min ,1M)
|
|
No Breakdown
|
|
|
|||
|
Voltage Rating
|
|
75V
|
|
|
|||
|
Operating temperat
|
|
-20℃ to 60℃
|
|
|
|||
