Photovoltaic Modules
|
|
|
|
|
|
|
||||||
|
Encapsulation
|
Glass/EVA/Cell/EVA/Backsheet
|
|
|
|
|
|
||||||
|
Size and Number of cells
|
166mm 108/2*54pcs
|
|
|
|
|
|
||||||
|
Maximum Power P
mp
(W)
|
405
|
410
|
415
|
420
|
425
|
|
||||||
|
Open Circuit Voltage (Voc/V)
|
37
|
37.25
|
37.5
|
37.75
|
37.96
|
|
||||||
|
Short Circuit Current (lsc/A)
|
13.83
|
13.88
|
13.94
|
14.01
|
14.08
|
|
||||||
|
Voltage at Maximum Power(Vmp/V)
|
31
|
31.25
|
31.49
|
31.73
|
31.94
|
|
||||||
|
Current at Maximum Power (Imp/A)
|
13.07
|
13.12
|
13.18
|
14.19
|
14.26
|
|
||||||
|
Module Efficiency (%)
|
20.7%
|
21%
|
21.3%
|
21.5%
|
21.8%
|
|
||||||
|
Tolerance
|
0+3%
|
|
|
|
|
|
||||||
|
Max System Open Circuit Voltage
|
1500V
|
|
|
|
|
|
||||||
|
Max Series Fuse Rating
|
25A
|
|
|
|
|
|
||||||
|
Junction Box (Protection Degree)
|
IP68
|
|
|
|
|
|
||||||
|
Dimension(W'D*L)
|
1722x1134x30mm
|
|
|
|
|
|
||||||
|
Weight
|
20.8kg
|
|
|
|
|
|
||||||
|
Frame Color
|
Black/Silver
|
|
|
|
|
|
||||||
