Automatic swing door opener PKM C02
Input voltage: DC24V
Main supply: 110V/220V,60Hz/50Hz
Motor's power: 60W
Rotational speed: 100PRM
Rod's running speed: 2.4cm/s
Protection class: IP55
Safety clutch: Electronic current sensing
Limit Switch: Without
Backup battery: 12V /(5 or 7.0AH)
Safety device: Infrared sensor(optional)
Remote controller: UHF Digital PWM type
Temperature: -20 degree to +55 degree
Max single-leaf length : 3m
Max single-leaf weight : 300KG
- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Hotel
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Giant swing gate opener
-
Model Number:
-
JJ -PKM- C023
-
Type:
-
Automatic Door Operators
-
Motor's Power:
-
24VDC 60W
-
single-leaf length:
-
3m
-
rod's running speed:
-
2.4cm/s
-
single-leaf weight::
-
300KG swing gate opener
-
Continunous working time:
-
5 minutes
-
rotational speed:
-
100PRM
-
protection calss:
-
IP55 swing gate opener
-
Gross weight:
-
20KG
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support, Free spare parts
-
Project Solution Capability:
-
total solution for projects
-
Application:
-
Hotel
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Giant swing gate opener
-
Model Number:
-
JJ -PKM- C023
-
Type:
-
Automatic Door Operators
-
Motor's Power:
-
24VDC 60W
-
single-leaf length:
-
3m
-
rod's running speed:
-
2.4cm/s
-
single-leaf weight::
-
300KG swing gate opener
-
Continunous working time:
-
5 minutes
-
rotational speed:
-
100PRM
-
protection calss:
-
IP55 swing gate opener
-
Gross weight:
-
20KG
Products Description
Solar full set includes:2 arm
120W solar panel with brackets
2 pcs 12V 7AH/9AH battery
1 solar charger
1 big box
2 remote control
1 set hardware accessories
120W solar panel with brackets
2 pcs 12V 7AH/9AH battery
1 solar charger
1 big box
2 remote control
1 set hardware accessories
1.Worm gear provides durability and silence in motor operation.
2.Clutch device for power failure,use a special key release clutch,operate the gate manually.
3.Stop working when gate meets obstacle.
4.Soft start and soft stop ,avoid some accidents
5.Copper motor and gear worm for stable performance and longer working life
6.Adjustable opening/closing interval between master and slave gate.
7.Adjusting residence sensitivity
8.24VDC Swing gate opener can work for solar power system and back up battery
2.Clutch device for power failure,use a special key release clutch,operate the gate manually.
3.Stop working when gate meets obstacle.
4.Soft start and soft stop ,avoid some accidents
5.Copper motor and gear worm for stable performance and longer working life
6.Adjustable opening/closing interval between master and slave gate.
7.Adjusting residence sensitivity
8.24VDC Swing gate opener can work for solar power system and back up battery
Technical data
Title goes here.
Manual release
Quick release design in case of power failure
Moving part , without rod actuator
control board EG-22A
Application:Used for DC swing gate opener
Voltage: DC 24V
Protection fuse: 10A
Board Memory: 120 rolling code transmitters
frequency: 433.92mhz (other frequency customized)
Output Voltage: DC 12V-24V
Led digital seting and potentiometer setting optional
