Quick Details
-
Brand Name:
-
LEYE
-
Model Number:
-
LY-A03-03
-
Advantage:
-
suitable for high-density mounting
-
Rating:
-
50mA.12V DC
-
Insulation resistance:
-
100MΩ min 100V DC
-
Dielectric strength:
-
250V AC for 1min
-
Contact resistance:
-
50MΩ max
-
Operating temperature range:
-
-20°c to +70°c
-
Lifetime:
-
50,000 Cycles min
-
Operating force:
-
250gf
-
Travel:
-
0.20±0.05mm
Quick Details
-
Max. Current:
-
50MA
-
Max. Voltage:
-
12V DC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LEYE
-
Model Number:
-
LY-A03-03
-
Advantage:
-
suitable for high-density mounting
-
Rating:
-
50mA.12V DC
-
Insulation resistance:
-
100MΩ min 100V DC
-
Dielectric strength:
-
250V AC for 1min
-
Contact resistance:
-
50MΩ max
-
Operating temperature range:
-
-20°c to +70°c
-
Lifetime:
-
50,000 Cycles min
-
Operating force:
-
250gf
-
Travel:
-
0.20±0.05mm
|
Rated Current
|
50mA
|
|
Rated Voltage
|
12V
|
|
Contact Resistance
|
≤50mΩ Max
|
|
Insulation Resistance
|
≥100mΩ 100V DC
|
|
Compressive Strength
|
AC250V 50Hz/1min
|
|
Mechanical Life
|
50000 cycles min
|
|
Operating Stroke
|
0.25±0.05mm
|
|
Operating Force
|
250gf±50gf
|
|
Temperature Range
|
-25℃~+70℃
|
