2. Meet the general needs of different farm tools, it has water cooling system, four stroke, hydraulic suspension, PTO speed 540rpm, strong lifting force.
3. Large tank can work for a long time.
- Product Details
- {{item.text}}
Quick Details
-
Engine Brand:
-
Chinese Famous Brand
-
Weight:
-
750 KG
-
Product name:
-
tractor
-
Model:
-
T-220
-
Ground clearance mm:
-
270
-
Rear wheel size:
-
9.15 "- 16"
-
Front wheel size:
-
6.00 "- 12"
-
Track mm:
-
1100-1350
-
Gear type:
-
Mechanical
-
Type of brake system:
-
Sealed disc brake
-
Sound signal:
-
Horn
-
Number of gears:
-
6+2
Quick Details
-
Brand Name:
-
langpak
-
Place of Origin:
-
Shandong, China
-
Marketing Type:
-
Hot Product 2023
-
Engine Brand:
-
Chinese Famous Brand
-
Weight:
-
750 KG
-
Product name:
-
tractor
-
Model:
-
T-220
-
Ground clearance mm:
-
270
-
Rear wheel size:
-
9.15 "- 16"
-
Front wheel size:
-
6.00 "- 12"
-
Track mm:
-
1100-1350
-
Gear type:
-
Mechanical
-
Type of brake system:
-
Sealed disc brake
-
Sound signal:
-
Horn
-
Number of gears:
-
6+2
High Quality 3 Point Rototillers 15-40 HP Tractor Hitch Cultivator Rotary Tiller tractor
Discounts and gifts for you!!! Send an inquiry
Products Description
Work efficiency
1. 3 * 2F + 1R multi-gear speed change is adopted, with more gear and speed matching and high work efficiency.
3. Large tank can work for a long time.
3. Large tank can work for a long time.
Technical parameters
|
Model
|
Model
|
T-180
|
T-200
|
T-220
|
||
|
|
Power & Type
|
18HP, 4×2
|
20HP, 4×2
|
22HP, 4×2
|
||
|
Engine
|
Model
|
ZS1105
|
ZS1110
|
ZS1115
|
||
|
|
Bore×Stroke(mm)
|
105
|
110
|
115
|
||
|
|
Cooling System
|
Water-Cooled, Four Strokes,Direct in Injection
|
|
|
||
|
|
Starting System
|
Electrical Starting
|
|
|
||
|
Dimension
|
Size L*W*H (mm)
|
2400×1310×1750
|
|
|
||
|
|
Wheel Base (mm)
|
1100~1400
1370 |
|
|
||
|
|
Wheel Tread (mm) F/R
|
F:960/1100/1200 R: Adjustable 860~1300
|
|
|
||
|
|
Min Ground Clearance(mm)
|
270
|
|
|
||
|
|
Structure Weight(kg)
|
750
|
|
|
||
|
Transmission
|
Type
|
Sliding
|
|
|
||
|
|
No. of Gear
|
(3F + 1R)×2
|
|
|
||
|
|
Clutch Type
|
Dry, Double Discs, Normally Jointing and Fricting Type
|
|
|
||
|
Running System
|
Tyre F/R
|
6.00-12/9.50-16/7.50-20
|
|
|
||
|
|
Steering
|
Mechanical Steering
|
|
|
||
|
|
Brake
|
Toe Type Brake
|
|
|
||
|
|
Sensors On The Dashboard
|
Water Temperature Gauge, Oil Pressure Gauge
|
|
|
||
|
|
|
Ammeter Electric, Hour Meter Electric
|
|
|
||
|
Working System
|
Hitch System
|
3-Point hydraulic hitch
|
|
|
||
|
|
PTO
|
Rear Rectangle Spline, 6 Teeth
|
|
|
||
|
|
PTO Speed
|
540rpm
|
|
|
||
It can be applied to the greenhouse, hilly field and other narrow and complex terrain in favor of improving work efficiency.
Mechanical steering, high reliability.
Double reinforced clutch, more reliable power take-off coupling.
Double reinforced clutch, more reliable power take-off coupling.
Matching with Changchai zs11 series engine, it has large torque reserve, strong power and high operation efficiency.
Different color and hood for you to choose
