- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
HF oven rotary switch
-
Model Number:
-
LW5D-16 oven rotary switch
-
Max. Current:
-
40a
-
Mechanical Life:
-
10,000,000times
-
model number:
-
LW5D-16 oven rotary switch
-
panel:
-
OFF-ON
-
Color:
-
red/yellow
-
Have stock:
-
YES oven rotary switch
-
service:
-
OEM/ODM
-
Warranty:
-
2 years
-
packing:
-
Standard exporting carton
-
Delivery Detail:
-
within 7 days
-
Certification:
-
CE ISO9001, CE
-
Frequency:
-
50Hz oven rotary switch
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
690V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HF oven rotary switch
-
Model Number:
-
LW5D-16 oven rotary switch
-
Max. Current:
-
40a
-
Mechanical Life:
-
10,000,000times
-
model number:
-
LW5D-16 oven rotary switch
-
panel:
-
OFF-ON
-
Color:
-
red/yellow
-
Have stock:
-
YES oven rotary switch
-
service:
-
OEM/ODM
-
Warranty:
-
2 years
-
packing:
-
Standard exporting carton
-
Delivery Detail:
-
within 7 days
-
Certification:
-
CE ISO9001, CE
-
Frequency:
-
50Hz oven rotary switch
Product Description
Details Images
Specification
Introduction:
LW5D applied to change over of circuits,also for control of electrical measuring instruments and control of motors.Mechanical life without load:0.3×106times,operation frequency is 300 times/h..Mechanical life with load:AC-15 DC-13 IS
0.01×104times operation frequency is 300 times/h.
AC-3 is 0.1×104times operation frequency is 120 times/h.
AC-4 is 0.1×104times operation frequency is 120 times/h.
LW5D applied to change over of circuits,also for control of electrical measuring instruments and control of motors.Mechanical life without load:0.3×106times,operation frequency is 300 times/h..Mechanical life with load:AC-15 DC-13 IS
0.01×104times operation frequency is 300 times/h.
AC-3 is 0.1×104times operation frequency is 120 times/h.
AC-4 is 0.1×104times operation frequency is 120 times/h.
|
Uses
|
|
Master Control
|
Diredt control motor
|
|
|
|
|
|
|
||||||
|
Rated thermal current
|
ITH
|
A
|
16
|
|
|
|
|
|
|
||||||
|
Rated working voltage
|
Ue
|
V
|
125
|
220
|
250
|
380
|
440
|
500
|
380
|
||||||
|
Rated working current
|
Le
|
A
|
|
|
|
|
|
|
|
||||||
|
AC-15
|
|
A
|
|
4.6
|
|
2.6
|
|
2.0
|
|
||||||
|
DC-3
|
|
A
|
|
|
|
|
|
|
12
|
||||||
|
AC-4
|
|
A
|
|
|
|
|
|
|
3.5
|
||||||
|
DC-13Double breakpoint
|
|
A
|
0.55
|
|
0.27
|
|
|
0.14
|
|
||||||
|
DC-13four breakpoint
|
|
A
|
0.82
|
|
0.41
|
|
|
0.2
|
|
||||||
