Quick Details
-
Brand Name:
-
TIANXUN
-
Model Number:
-
Discover Deluxe TX-850
-
Product name:
-
Metal Detector
-
Application:
-
Treasure Hunter Finder
-
Sensitivity:
-
Big Coil: 35~40cm
-
Certificates:
-
CE/ROHS/ISO9001
-
Color:
-
Black
-
Power supply:
-
9V Battery
-
Usage:
-
Gold Hunting
-
Certification:
-
CE/ROHS/ISO9001
Quick Details
-
Warranty:
-
12 months, 12 Months
-
Type:
-
metal detectors for gold, Low Frequency Induction(VLF)
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
TIANXUN
-
Model Number:
-
Discover Deluxe TX-850
-
Product name:
-
Metal Detector
-
Application:
-
Treasure Hunter Finder
-
Sensitivity:
-
Big Coil: 35~40cm
-
Certificates:
-
CE/ROHS/ISO9001
-
Color:
-
Black
-
Power supply:
-
9V Battery
-
Usage:
-
Gold Hunting
-
Certification:
-
CE/ROHS/ISO9001
Specification:
DISCOVER Deluxe Shanghai Tianxun produce high sensitivity 15" search coil gold metal detector
|
Specification |
|
|
Power supply |
9Vbattery(not including) |
|
Sensitivity |
>30cm (for a US quarter) |
|
Operation modes |
LCD screen indication for metal |
|
Coil |
11.5"*15'' DD waterproof search coil |
|
Audio |
3 tones audio |
|
Detected indication |
Digitial LCD screen |
|
Battery Condition Indicator |
Yes |
|
Distinguish |
Ferrous and non-ferrous |
|
Frequency |
19KHz |
|
Ground Balance |
√ |
|
Target ID |
0-100 |
|
Pinpoint function |
√ |
|
Warranty |
1 year |
Mechanical: S-rod with electronics housing on rod, 3-piece breakdown construction, nonmetallic telescoping lower rod, adjustable position armrest
Weight: 2 lbs, 8 oz with battery installed
Standard search coil: 11 inch search coil
Batteries: Single 9 volt rectangular alkaline
Operating principle: VLF induction balance
Operating frequency: 19 kHz, crystal controlled
Battery life: 15+ hours on good quality alkaline
Operating temp range: 14 to 122 degrees F (-10 to +50 C)
Operating humidity range: 0 - 90%
The following terms are used throughout the manual, and are standard
terminology among treasure hunters.
ELIMINATION
Referencetoametalbeing"eliminated"meansthatthedetectorwillnot
emitatone,norlightupanindicator,whenaspecifiedobjectpasses
through the search coil’s detection field.
DISCRIMINATION
Whenthedetectoremitsdifferenttonesfordifferenttypesofmetals,and
whenthedetector"eliminates"certainmetals,werefertothisasthe
detector "discriminating" among different types of metals.
Discriminationis an essentialfeatureof professionalmetaldetectors.
Discriminationallowstheuserto ignoretrashand otherundesirableobjects.
RELIC
Arelicisanobjectofinterestbyreasonofitsageoritsassociationwith
the past. Many relics are made of iron, but can also be made of bronze
or precious metals.
IRON
Ironisacommon,low-grademetalthatisanundesirabletargetincertain
metal detectingapplications. Examples ofundesirable iron objects are
oldcans,pipes,boltsandnails.
Sometimes,thedesiredtargetismadeofiron. Propertymarkers,for
instance,containiron. Valuablerelicscanalsobecomposedofiron;
cannon balls, old armaments, and parts of old structures and vehicles
canalsobecomposedofiron.
FERROUS
Metals which are made of, or contain, iron.
PINPOINTING
Pinpointingistheprocessoffindingtheexactlocationofaburiedobject.
Long-buried metals can appear to the eye exactly like the surrounding
soil,andcanthereforebeveryhardtoisolatefromthesoil.
V.C.O.
Meaning “voltage controlled oscillator”, the V.C.O.audio method
causes both the audio pitch and the volume to rise as signal
strength increases. V.C.O. improves the user’s ability to interpret a
target’s size and depth. Very weak signals (for small or very deeply
buried objects) have the faintest volume and the lowest pitch.
Larger objects, and those closer to the search coil, will induce a
higher volume and higher pitch sound.
GROUND BALANCE
Ground Balancing is the ability of the detector to ignore, or "see through" the
earth’snaturallyoccurringminerals,andonlysoundatonewhenametal
object is detected. The DISCOVER deluxe incorporates proprietary
circuitry and programming to eliminate false signals from severe ground
conditions.
