Quick Details
-
Keywords:
-
23 inch 18.5 touch screen panel kit
-
Interface:
-
USB/RS232/VGA/DVI/HD-MI
-
Touch points:
-
10 Points
-
Brightness:
-
300cd/m2
-
viewing angle:
-
89°/89°
-
Contrast Ratio:
-
1000:1
-
Operating System:
-
XP Win7 8 Android Linux
-
Warranty:
-
1 Year
Quick Details
-
Type:
-
TOT230UCA016-LED
-
Brand Name:
-
Toponetech
-
Place of Origin:
-
Guangdong, China
-
Keywords:
-
23 inch 18.5 touch screen panel kit
-
Interface:
-
USB/RS232/VGA/DVI/HD-MI
-
Touch points:
-
10 Points
-
Brightness:
-
300cd/m2
-
viewing angle:
-
89°/89°
-
Contrast Ratio:
-
1000:1
-
Operating System:
-
XP Win7 8 Android Linux
-
Warranty:
-
1 Year
S pecification
|
Model No. |
TOT230UCA112 |
||||
|
Series |
OT,Flat,Zero-bezel |
||||
|
Display Type |
16:9 Ratio 23"a-Si TFT-LCD,LED backlight |
||||
|
Display Active Area |
509.184mm×286.416mm |
||||
|
Monitor Dimension s |
Width
: 588.2mm
|
||||
|
Suggested Resolution |
1920×1080 @ 60Hz |
||||
|
Support Colors |
16.7M |
||||
|
Brightness(Typ.) |
Pure LCD Panel |
250cd/m2 |
|||
|
With PCAP Glass Sensor |
212cd/m2 |
||||
|
Response Time(Typ.) |
14ms |
||||
|
Viewing Angle (Typ.at CR>10)) |
Horizontal(left/right) |
89°/89° |
|||
|
Vertical(up/down) |
89°/89° |
||||
|
Contrast Ratio(Typ.) |
1000:1 |
||||
|
Video Input |
VGA ,DVI,HDMI |
||||
|
Frequency(H/V) |
30~80KHz / 60~75Hz |
||||
|
Power Supply |
Type: External brick
|
||||
|
Environment |
Operating Temp: |
0~50°C |
|||
|
Storage Temp: |
-20~60°C |
||||
|
Operating RH: |
20%~90% |
||||
|
Storage RH: |
5%~90% |
||||
|
MTBF |
30,000 Hours |
||||
|
LCD Back light Life(Typ.) |
30,000 Hours |
||||
|
Weight(Approx.) |
N.W:7.5Kg(single)/G.W:17.3Kg (2pcs in one package) |
||||
|
Power Consumption |
19W /0.55W(Standby) |
||||
|
Mount Interface |
1)VESA 100*300mm and 100*400mm 2)Mount bracket, horizontal or vertical |
||||
|
OSD Control |
Buttons |
AUTO,+,POWER,-,MENU |
|||
|
Function |
Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset |
||||
|
Touch screen Type |
Top One Tech 23”Projected Capacitive Touchscreen, 10 points in win7 |
||||
|
Touch System Interface |
Having USB interface |
||||
|
Touch Response time |
USB: <10ms |
||||
|
Agency Approval |
CCC, ETL, FCC, CE, RoHS |
||||
