Quick Details
-
Rich Interface:
-
1 COM + 6 USB
-
Many CPU:
-
Intel celeron J1800
-
Gold Supplier:
-
Yes
-
OEM Accepted:
-
dual screen touch pos system
-
RAM:
-
4GB(8GB, 16GB Optional)
-
HDD:
-
250G/500G
-
Optional function:
-
VFD220,LED8,Cash drawer,Barcode scanner
-
SSD:
-
32G,64G
-
Screen size:
-
15 +15 Inch
-
Keyword:
-
Touch POS Cashier Machine
-
Operation System:
-
Win7/8/10, Linux
-
Hard Disk Capacity:
-
32GB
Quick Details
-
Brand Name:
-
Detaik/OEM
-
CPU:
-
J1800
-
Place of Origin:
-
Guangdong, China
-
Rich Interface:
-
1 COM + 6 USB
-
Many CPU:
-
Intel celeron J1800
-
Gold Supplier:
-
Yes
-
OEM Accepted:
-
dual screen touch pos system
-
RAM:
-
4GB(8GB, 16GB Optional)
-
HDD:
-
250G/500G
-
Optional function:
-
VFD220,LED8,Cash drawer,Barcode scanner
-
SSD:
-
32G,64G
-
Screen size:
-
15 +15 Inch
-
Keyword:
-
Touch POS Cashier Machine
-
Operation System:
-
Win7/8/10, Linux
-
Hard Disk Capacity:
-
32GB
Specification
|
Model No.
|
POS1566-J18A
|
|
|
Main Board
|
|
|
|
CPU
|
Intel® Celeron® J1800(J1900 Optional),Dual-core, clock speed up to 2.58G, TDP 10W
|
|
|
Chipset
|
Intel Bay Trail-D
|
|
|
Motherboard
|
industrial motherboard Fanless
|
|
|
System Memory
|
Support DDR3L 1333 MHz, 2G up to 8GB
|
|
|
OS Support
|
Win 7,Win 8,win 10, Linux
|
|
|
Storage
|
|
|
|
SSD/HDD
|
Industrial 32G 64G 128G SSD or 500G HDD(2.5” SATA)
|
|
|
SATA Slot
|
1 * mSATA Slot
|
|
|
Display
|
|
|
|
LCD Panel
|
Industrial 15" TFT LED
|
|
|
Resolution
|
1024*768 (max) @ 60Hz
|
|
|
Brightness
|
300 cd/㎡
|
|
|
Ilting Angle
|
35-90 Degree
|
|
|
Touch Screen
|
5 Wire Resistive(All planar Resistive or capacitive optional) touch panel
|
|
|
I/O Ports
|
|
|
|
USB
|
USB2.0: 6 * Rear I/O + 2 * Header ((Internal, reserved for touch screen,MSR)
|
|
|
Serial
|
1 * COM（DB9）
|
|
|
LAN
|
1 * Realtek FE LAN chip (10/100/1000 Mbps)
|
|
|
VGA
|
1 * VGA（DB15）
|
|
|
Audio
|
ALC662 5.1 Channel HDA Codec , Support MIC/Line-out Ports
|
|
|
DC
|
1 * DC Power Input
|
|
|
Environment
|
|
|
|
Power
|
DC 12V 5A
|
|
|
Operating Tem
|
0℃ to 40℃
|
|
|
Storage Tem
|
－20℃ to 60℃
|
|
|
Other Optional
|
MSR, Customer Display, Second Display,Wifi optional
|
|
