Quick Details
-
Color:
-
Full Color
-
Panel Size:
-
500*500mm, 500*500mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
RX390-floor
-
Product Name:
-
P3.9 P3.91 Dance Floor Interactive Led Display
-
Cabinet size:
-
500*500*87mm
-
Cabinet weight:
-
7.5Kgs
-
Module Size:
-
250*250mm
-
Scan mode:
-
1/16
-
Maintainance type:
-
front and rear access
-
Cabinet Material:
-
Die Casting Alunimum
-
Brightness:
-
4000-5000 nits
-
Refresh Rate:
-
3840Hz
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
Canbest
-
Color:
-
Full Color
-
Panel Size:
-
500*500mm, 500*500mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
RX390-floor
-
Product Name:
-
P3.9 P3.91 Dance Floor Interactive Led Display
-
Cabinet size:
-
500*500*87mm
-
Cabinet weight:
-
7.5Kgs
-
Module Size:
-
250*250mm
-
Scan mode:
-
1/16
-
Maintainance type:
-
front and rear access
-
Cabinet Material:
-
Die Casting Alunimum
-
Brightness:
-
4000-5000 nits
-
Refresh Rate:
-
3840Hz
Warranty
Technical Parameter
|
Usage
|
indoor
|
outdoor
|
outdoor
|
|||
|
Pixel Pitch
|
2.6 mm
|
3.9 mm
|
4.8 mm
|
|||
|
LED Type
|
SMD1515
|
SMD1921
|
SMD2525
|
|||
|
Physical Density
|
147,456 dot/m²
|
65,536 dot/m²
|
43,222 dot/m²
|
|||
|
Panel Size (W×H×D)
|
500x500x87 mm
|
500x500x87 mm
|
500x500x87 mm
|
|||
|
Panel Material
|
Die Casting Aluminum
|
Die Casting Aluminum
|
Die Casting Aluminum
|
|||
|
Panel Weight
|
7.5 kg
|
7.5 kg
|
7.5 kg
|
|||
|
Panel Flatness
|
≤0.10 mm
|
≤0.10 mm
|
≤0.10 mm
|
|||
|
Color Depth
|
16 Bit
|
16 Bit
|
16 Bit
|
|||
|
Brightness
|
≥1000 cd/㎡
|
≥4000 cd/㎡
|
≥4000 cd/㎡
|
|||
|
Viewing Angle
|
≥140° (H) / 140° (V)
|
≥140° (H) / 120° (V)
|
≥140° (H) / 120° (V)
|
|||
|
Scanning Mode
|
1/32
|
1/16
|
1/13
|
|||
|
Refresh Rate
|
≥3840Hz
|
≥3840Hz
|
≥3840Hz
|
|||
|
Input Voltage AC
|
110~220V
|
110~220V
|
110~220V
|
|||
|
Max. Power Consumption
|
≤500 w/㎡
|
≤800 w/㎡
|
≤800 w/㎡
|
|||
|
Ave. Power Consumption
|
≤160 w/㎡
|
≤268 w/㎡
|
≤268 w/㎡
|
|||
|
Working Temperature
|
-10℃～+40℃
|
-10℃～+40℃
|
-10℃～+40℃
|
|||
|
Working Humidity
|
10%～90%RH
|
10%～90%RH
|
10%～90%RH
|
|||
|
Configurations of Dance Floor LED Screen
|
|
|
|
|||
|
Supporting Legs
|
√
|
√
|
√
|
|||
|
Loading Capacity
|
2 t/㎡
|
2 t/㎡
|
2 t/㎡
|
|||
|
Dedicated PC Cover
|
√
|
√
|
√
|
|||
|
High-transparency Acrylic Plate
|
√
|
optional
|
optional
|
|||
|
Protection Grade
|
IP40
|
IP65
|
IP65
|
|||
|
Lifespan
|
≥100,000 hrs
|
≥100,000 hrs
|
≥100,000 hrs
|
|||
|
Maintenance Type
|
Front and Rear
|
Front and Rear
|
Front and Rear
|
|||
|
Configurations of Control System
|
|
|
|
|||
|
Sync. Control System
|
√
|
√
|
√
|
|||
|
Radar System
|
√
|
√
|
√
|
|||
|
Control Software
|
√
|
√
|
√
|
|||
Product Description
Does external interactive system comes pre loaded with games?
Product packaging
