Product Details

{{item.text}}

Quick Details

Inner box volume:: 0.5M3, depth x width x height: 60x 95x 90cm

Size:: DxWxH: 61x 120x 105cm

Glow wire:: make a ring with a diameter of 4.0mm with nickel/chromium wire

Heating current:: the current is between 120~150A when the temperature is 960°C

The force applied to the test:: 0.8~1.2N, and the limit of the indentation depth is at least 7mm

Timing:: ignition duration (Ti) and flame extinguishing time (T)

Quick Details

Warranty:: 1 Year

Place of Origin:: Hebei, China

Brand Name:: btutest

Inner box volume:: 0.5M3, depth x width x height: 60x 95x 90cm

Size:: DxWxH: 61x 120x 105cm

Glow wire:: make a ring with a diameter of 4.0mm with nickel/chromium wire

Heating current:: the current is between 120~150A when the temperature is 960°C

The force applied to the test:: 0.8~1.2N, and the limit of the indentation depth is at least 7mm

Timing:: ignition duration (Ti) and flame extinguishing time (T)

Glow wire tester

Glow Wire Tester Stainless steel touch screen in line with standards Support non-standard customization Glow wire testing machine is used for electricians and their components and components, and is also suitable for solid electrical insulating materials or other solid combustible materials, in line with GB/T5169.10~13, IEC60695-2-1/0~2-1/3, GB2099, VDE 0620, GB4706, UL817 test standards. Test method: Heat the gauge wire loop to the specified temperature, and then make the glow wire and the test sample come into contact under the test conditions. The plug and socket glow wire testing machine is often used in electricians and their components and components, and is also suitable for solid electrical insulation materials or other solid combustible materials, in line with GB/T5169.10~13, IEC60695-2-1/0~2-1/3, GB2099, VDE 0620, GB4706, UL817 test standards. Test method: heat to the specified temperature with a standardized resistance wire ring, and then make the glow wire and the test sample contact with the plug, socket, rubber and plastic and other products under the conditions of the test.

Specification

1. Inner box volume: 0.5M3, depth x width x height: 60x 95x 90cm 2. Size: DxWxH: 61x 120x 105cm 3. Glow wire: make a ring with a diameter of 4.0mm with nickel/chromium wire 4. Temperature measuring device: 0.5mm armored filament thermocouple, able to withstand high temperature of 1050°C 5. Heating current: the current is between 120~150A when the temperature is 960°C 6. The force applied to the test: 0.8~1.2N, and the limit of the indentation depth is at least 7mm 7. Timing: ignition duration (Ti) and flame extinguishing time (T） 8. The material and size can be customized according to customer requirements.

Product Description

Performance benefits

Glow wire testing machine is used for electricians and their components and components, and is also suitable for solid electrical insulating materials or other solid combustible materials, in line with GB/T5169.10~13, IEC60695-2-1/0~2-1/3, GB2099, VDE 0620, GB4706, UL817 test standards.

The plug and socket glow wire testing machine is often used in electricians and their components and components, and is also suitable for solid electrical insulation materials or other solid combustible materials, in line with GB/T5169.10~13, IEC60695-2-1/0~2-1/3, GB2099, VDE 0620, GB4706, UL817 test standards.
