Quick Details
Quick Details
-
Place of Origin:
-
Shanghai, China
-
TYPE:
-
T30
2475k5/8 iNGERSOLL RAND T30 PISTON AIR COMPRESSOR/ 5.5HP 4KW/8BARG HORIZONTAK TANK/0.49M3.MIN 150L TANK 270KGS
Ingersoll Rand Piston air compressor 2340B3/8
reciprocating air compressor/ 8barg 3hp 2kw 0.27m3/min 80L horizontal tank /170kgs
| MODEL | POWER | CAPACITY | SPEED | TANK | SIZE | WEIGHT | |
| HP | KW | m3/min | R/min | L | mm | kg | |
|
8barg/ HORIZONTAL |
|||||||
| 2340B3/8 | 3 | 2 | 0.27 | 1105 | 80 | 1220X560X820 | 170 |
| 2475K5/8 | 5.5 | 4 | 0.49 | 1060 | 150 | 1550x600x900 | 220 |
| 2475K7/8 | 7.5 | 6 | 0.61 | 1344 | 150 | 1550x600x900 | 240 |
| 2545K7/8 | 7.5 | 6 | 0.71 | 765 | 150 | 1550X650X1080 | 270 |
| 2545K10/8 | 10 | 7 | 0.97 | 1025 | 150 | 1550X650X1080 | 274 |
| 7100C15/8 | 15 | 11 | 1.40 | 1100 | 230 | 1630X750X1170 | 445 |
| 7100C15/8-DL | 15 | 11 | 1.40 | 1100 | 230 | 1630X750X1170 | 445 |
| 7100C15/8-DL | 15 | 11 | 1.40 | 1100 | 230 | 1630X750X1170 | 445 |
| 7100C15/8-AC-DL | 15 | 11 | 1.40 | 1100 | 230 | 1630X750X1170 | 450 |
| 7100C15/8-AC-DL | 15 | 11 | 1.40 | 1100 | 230 | 1630X750X1170 | 450 |
| 3000D20/8 | 20 | 15 | 2.00 | 740 | 300 | 1680x900x1250 | 590 |
| 3000D25/8 | 25 | 19 | 2.40 | 933 | 300 | 1680x900x1250 | 620 |
| 3000D30/8 | 30 | 22 | 2.71 | 1045 | 300 | 1680x900x1250 | 690 |
| 3000D30/8-AC-LOL | 30 | 22 | 2.71 | 1045 | 300 | 1680x950x1250 | 700 |
INGERSOLL RAND 2 STAGE CAST IRON RECIPROCATING AIR COMPRESSOR PREMIERE PACKAGE
Detachable Baseplate 175 PSIG:
|
Model |
Power KW |
Capacity m3/min ft3/min |
Operating Pressure bar(g) psi(g) |
Dimensions (mm) L×W×H |
Weight Kg |
Air Tank Litre |
||
|
2340XD3/12 |
2.2 |
0.27 |
9.6 |
12.3 |
175 |
870Lx490Wx535H |
109kg |
W/O |
|
2340XDV3/12 |
2.2 |
0.27 |
9.6 |
12.3 |
175 |
870Lx490Wx535H |
98kg |
W/O |
|
2340XD5/12 |
4.1 |
0.38 |
13.2 |
12.3 |
175 |
870Lx490Wx535H |
110kg |
W/O |
|
2340XDV5/12 |
4.1 |
0.38 |
13.2 |
12.3 |
175 |
870Lx490Wx535H |
101kg |
W/O |
|
2475XD5/12 |
4.1 |
0.48 |
17.1 |
12.3 |
175 |
1040Lx530Wx570H |
130kg |
W/O |
|
2475XDV5/12 |
4.1 |
0.48 |
17.1 |
12.3 |
175 |
930Lx530Wx570H |
130kg |
W/O |
|
2475XD7/12 |
5.6 |
0.61 |
21.5 |
12.3 |
175 |
1040Lx530Wx570H |
140kg |
W/O |
|
2475XDV7/12 |
5.6 |
0.61 |
21.5 |
12.3 |
175 |
930Lx530Wx570H |
140kg |
W/O |
|
2545XD7/12 |
5.6 |
0.70 |
24.7 |
12.3 |
175 |
1035Lx681Wx684H |
221kg |
W/O |
|
2545XDV7/12 |
5.6 |
0.70 |
24.7 |
12.3 |
175 |
1035Lx681Wx684H |
221kg |
W/O |
|
2545XD10/12 |
7.5 |
0.97 |
34.0 |
12.3 |
175 |
1035Lx681Wx684H |
229kg |
W/O |
|
2545XD10/12SD |
7.5 |
0.97 |
34.0 |
12.3 |
175 |
1035Lx681Wx684H |
229kg |
W/O |
|
2545XDV10/12 |
7.5 |
0.97 |
34.0 |
12.3 |
175 |
1035Lx681Wx684H |
229kg |
W/O |
- Regulation: Auto Stop/Start, 2340 thru 2545 series, H2340 thru H15T series
- Centrifugal unloader for no load start on 2545, series, prevents motor from starting under load. Eliminates possibility of motor burn out
- 100% cast icon frame and separately-cast cylinders
- Precison machined high quality cast iron cylinders with deep radial fins, suitable for heavy duty operation and longer life
- Heat treated stainles steel finger valve assemby, provides a large flow are resulting in lesser heat and carbon build-up. Easy removal & servicing
- Efficient finned intercooler tubes.
- Runs cooler, resulting in a more efficient compressor that consumes lesser power and lasts longer
- Balanced overhung crankshaft
- Precision balanced for smooth running with replaceable crankpin bushing that protects the crankshaft from damage
- Rugged one-piece connecting rod
- Solid-end precision type. No bolts or nuts which can come loose
- Factory-filled syntetic lubricants, reduces carbon buildup, extends lubricant change period. Improves compressor performance and life span
- DOL starter mounted on machine, SDS starter shipping loose with horsepower 20hp and above
What do you get from a Premiere Package?
- Heavy duty cast iron pump
- Full time low oil level protection switch
- Efficient electric motor; TEFC IP54 protection, Clss Finsulation (Three phase)
- Highly reliable magnetic starter; Star Delta (15hp - 30hp)
- Aircooled after-cooler
- Time proven parts and components
- Totally enclosed wired sheetmetal beltguard for premiere packages
- ASME coded air receiver with 3rd party certification
- Heavy duty cast iron pump
- 100 acfm capacity at 125psi
- Premium quality
- Powder coat painting enhances antirust
- 1100rpm reciprocating pump
- Efficient cooling system
- Oil level safety switch
- Mounted on 120 gallon Air Receiver tank
- Regulation: Auto Stop/Start, 2340 thru 2545. Constant speed 7100 thru 3000 series
- Tank mounted model, starter mounted on machine
- Baseplate mounted model, DOL starter mounted on machine, SDS starter shipping loose with machine
What do you get from a Standard Package
- Direct-on-line starter on standard package power below 15HP (includes 15HP)
- Totally enclosed wired beltguard
- Oil level sight glass
- Interstage safety valve & pressure gauge
- Discharge check valve & safety valve
- Manual drain valves on interstage drain legs
- Efficient TEFC electric motor, IP54, 1.15 S.F
- Rugged steel baseplate
- Factory filled XL740HT synthetic lubricant
T30 3000E Series:
Reciprocating Air Compressors
Ingersoll Rand has maintained a delicate balance between known performance and new technology developments to manufacture world class reciprocating air compressors. With a proven design and stellar track record, the Ingersoll Rand reciprocating compressor family has earned worldwide recognition for reliable, trustworthy performance that saves money and enhances business success through: Lower life cycle costs; An ability to thrive in punishing applications; Configurations that meet varying needs; Optimum solutions for greater efficiency; Our cumulative experience with how different users prefer, need and operate their compressors has taught us what is most important to compressor users.
Electric-Driven Two-Stage Air Compressors
T30 Two Stage Reciprocating Compressor
3000E25/8
The Ingersoll-Rand T30 has been the leader in its class since it was introduced in 1929. Whether this is measured by reliability, efficiency, rugged flexibility or maintainability, it has no equal.
Designed for heavy industrial applications, the two stage reciprocating air compressors provide the quality and performance that exceed customer requirements.
Others may claim to handle heavy duty applications, but the T30 defines the concept. Run it in the most demanding intermediate duty application imaginable.
It won’t make any difference because this compressor performs with total dependability in the most demanding, heavy-duty industrial applications.
Throughout this brochure we try to show you some of the features which make the T30 unique and ideal to meet your demands of a compressor package in the 2-30 HP range.
Many compressor applications need care and experience to ensure that the correct machine and configuration is selected to provide the level of efficiency and reliability which you expect.
Our Sales offices and Distributors are ideally qualified and experienced to assist you in this task. If you are seeking information about a new compressor, advice about an existing installation or ancillary equipment or spare parts, you will find knowledge available to assist you.
Designed for heavy shop or industrial use, Ingersoll Rand Electric-driven Two-stage air compressors provide the reliability and performance that are ideal for most applications and users including automotive service and body shops, fleet maintenance, machine shops, production and manufacturing lines, wood working shops, dry cleaners, car washes, general maintenance/repair shops and farms.
FEATURES:
-
Durable cast iron design for 100% continuous duty application
-
Precision engineered components for high reliability
-
Individually cast cylinders, overhung crankshaft and one piece connecting rod for ease of maintenance and service
-
High efficiency finger valves
-
175 psig maximum operating pressure for applications requiring high air capacity and pressure
-
Extended 2 year warranty when used with Ingersoll Rand’s All Season Select synthetic lubricant
-
Choice of Value, Value Plus and Premium packages to suit diversified customer needs
Standard Features
• CE Marked receivers to 87/404/EEC
• 4 pole IP55 TEFV Motor
• Standard voltage 400-3-50
• Auto Start and Stop regulation by pressure switch up to 7.5 hp
• Dual control regulation on 10hp to 30hp receiver mounted units
• Constant Speed Control on 10hp to 30hp Base Mounted units
• DOL starting by pressure switch up to 7.5hp
• DOL starter (10hp to 30hp)
• Star Delta Starter available from 5.5hp
• Low oil level switch fitted from 10hp to 30hp
• Totally enclosed belt guard design
• Dry type inlet filter
• Flexible discharge tube
• Factory-fill of lubricant
